Qiymət sorğusu- Camera
- Camera Case TypeBullet
- Image Sensor1/3″ Progressive Scan CMOS
- Min. Illumination
Bullet：Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux @ (F1.6, AGC ON)
Dome：Color: 0.04 Lux @ (F2.0, AGC ON),B/W: 0.01 Lux @ (F2.0, AGC ON),0 Lux with IR
- Day &NightIR cut filter
- WDRDigital WDR
- Angle Adjustment
Bullet：Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Dome：Pan: 0° to 345°,tilt: 0° to 80°
- Protection LevelIP66
- Wi-Fi SupportYes
- Camera/General
- Power Supply
Bullet：12 VDC ± 25%, 0.6 A, max. 7.2 W,Ø5.5 mm coaxial power plug,reverse polarity protection,*A switching adapter is included in the package.
Dome: 12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug
- Consumption
Bullet：Max.7.2 W
Dome：Max.9 W
- Working Temperature
Bullet：-30 °C to 50 °C (-22 °F to 122 °F)
Dome：-10 °C to 40 °C (-14 °F to 104 °F)
- Working HumidityHumidity 95% or less (non-condensing)
- Dimension (W × D × H)
Bullet：94.1 mm × 75 mm × 174.5 mm (3.7″ × 3.0″ ×6.9″)
Dome：131.9 mm × 163.9 mm × 312.6 mm (5.19 × 6.45″ × 12.31″)”
Bullet：Approx. 270 g (0.6 lb.)
Dome：Approx. 600 g (1.32 lb.)
- Camera/Lens
- Focal Length2.8 mm
- Aperture
Bullet：F1.6
Dome：F2.0
- FocusFixed
- FOV
Bullet：horizontal FOV 109°, vertical FOV 61°, diagonal FOV 125°
Dome：horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
- Camera/IR
- IR Range
Bullet：White Light: up to 30 m; IR: up to 30 m
Dome：White light distance: up to 25 m,IR distance: up to 25 m
- Camera/Compression Standard
- Video Compression
Bullet：H264，H265
Dome：H.265, H.264, MJPEG
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Video Bit Rate
Bullet：32 Kbps to 4 Mbps
Dome：32 Kbps to 8 Mbps
- Audio CompressionG.711(ulaw)/ (AAC-LC)
- Audio Bit Rate64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz
- Environment Noise FilteringYes
- Camera/Image
- Max. Resolution1920 × 1080
- Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 x 432)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 x 432)
- Sub-stream
50 Hz: 25 fps (768 × 432)
60 Hz: 30 fps (768 × 432)
- Image SettingSaturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night Switch Day,Night,Auto,Schedule
- Camera/Network
- Alarm TriggerMotion detection (support alarm triggering by specified target types (human and vehicle))
- ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, UPnP
- General FunctionHeartbeat,mirror,password protection,anti-banding
- Camera/Interface
- Communication Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- Reset ButtonYes
- NVR/Video and Audio
- IP Video Input4-ch
- Incoming/Outgoing Bandwidth20 Mbps/20 Mbps
- NVR/Decoding
- Video Resolution6 MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Synchronous Playback2-ch
- NVR/Network
- Network Interface1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- NVR/Wi-Fi
- Frequency Band2.4 GHz
- Antenna StructureDual high gain antenna
- Transmission Speed573Mbps
- NVR/Auxiliary Interface
- SD Card2 slots,up to 512GB for each card
- NVR/General
- Power SupplyYes
- Consumption (without HDD and PoE off)≤ 6 W
- Working Temperature0 °C to 40 °C (32 °F to 104 °F)
- Working Humidity10 to 90 %
- Dimension (W × D × H)163 x 125 x 26 mm (6.4″ × 4.9″ × 1.0″)
- Weight (without hard disk)≤ 500 g (1.1 lb)
- Kit
- Accessories
Power cable: 2 × IPC power cables, 1 × NVS power cable
Ethernet cable: RJ45, Cat5e UTP, 1 m
- CertificationCE,CB
- Weight (with package)≤ 3 kg (6.6 lb)
