Qiymət sorğusuCamera Case Type | Bullet |
Image Sensor | 1/2.7″ Progressive Scan CMOS |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Day &Night | IR cut filter |
WDR | Digital WDR |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Protection Level | IP66 |
Material | Base: Metal, front cover: Metal, back cover: Plastic |
Wi-Fi Support | Yes |
Focal Length | 2.8 mm |
Aperture | F1.6 |
Focus | Fixed |
FOV | 2.8 mm, horizontal FOV: 112°, vertical FOV: 59°, diagonal FOV: 134° |
Lens Mount | M12 |
Video Compression | Main stream: H.265/H.264,;Sub-stream: H.265/H.264 |
H.265 Type | Main Profile |
Video Bit Rate | 32 Kbps to 8 Mbps |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
Audio Sampling Rate | 8 kHz/16 kHz |
Environment Noise Filtering | Yes |
Max. Resolution | 1920 × 1080 |
Main Stream | 50Hz: 25 fps (1920 × 1080, 1280 × 720);60Hz: 30 fps (1920 × 1080, 1280 × 720) |
Sub-stream | 50Hz: 25 fps (640 × 360) ;60Hz: 30 fps (640 × 360) |
Image Setting | Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv6, UDP, QoS, UPnP |
General Function | Heartbeat, anti-banding, mirror, password protection |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
Audio I/O | 1 built-in microphone |
Power Supply | 12 VDC ± 25%, 0.5 A, max 6 W, Ø5.5 mm coaxial power plug,reverse polarity protection, |
Consumption | ≤ 6 W |
Working Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
Working Humidity | 95% or less (non-condensing) |
Dimension (W × D × H) | 176.3 mm × 89.1 mm × 74.5 mm (6.9″ × 3.5″ × 2.9″) |
Weight | Approx. 350 g (0.8 lb.) |
Supplement Light Type | IR, White Light |
Supplement Light Range | Up to 30 m |
IP Video Input | 8-ch |
Incoming/Outgoing Bandwidth | 50 Mbps/40 Mbps |
HDMI/VGA Output | 1-ch, resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz;HDMI/VGA simultaneous output |
Audio Output | 1-ch, RCA (linear, 1 KΩ) |
Video Resolution | 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCI |
Synchronous Playback | 8-ch |
Capability | 4-ch@4 MP (12 fps), 4-ch@1080p (25 fps) |
Network Interface | 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
Frequency Band | 2.4 GHz |
Antenna Structure | 2 × 2MIMO |
Transmission Speed | 144 Mbps |
Transmission Standard | IEEE 802.11b/g/n |
Capacity | Up to 6 TB capacity |
USB Interface | 2 × USB 2.0 |
Consumption (without HDD and PoE off) | ≤ 10 W (without HDD) |
Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Working Humidity | 10% to 90% |
Dimension (W × D × H) | 265 × 246 × 48 mm (10.4″ × 9.7″ × 1.9″) |
Weight (without hard disk) | ≤ 1.6 kg (without HDD, 3.5 lb.) |
Power Supply | 12 VDC, 1.6 A |
Accessories | Power adaptor: 4 × IPC power adaptors, 1 × NVR power adaptor;Ethernet cable: RJ45, Cat5e UTP, 1 m. |
Certification | CE |
Weight (with package) | ≤ 7 kg (15.4 lb.) |
