Qiymət sorğusu- Camera
- Image Sensor
1/1.8 Progressive Scan CMOS（Camera）,
1/1.8 Progressive Scan CMOS（PTZ Camera）”
- Max. Resolution
2688 × 1520
- Min. Illumination
Color: 0.005 Lux @ (F1.5, AGC ON),
B/W: 0.0005 Lux @ (F1.5, AGC ON),
0 Lux with IR
- Shutter Time1/25 s to 1/12500 s
- Lens
- Lens Type
Fixed focal lens, 4 mm（Camera）,
Varifocal lens, motorized lens, 5.9 to 135.7 mm（PTZ Camera）
- Focal Length & FOV
4 mm, horizontal FOV 81°, vertical FOV 44°, diagonal FOV 94°,
5.9 to 135.7 mm, horizontal FOV 59° to 3°, vertical FOV 35° to 2°, diagonal FOV 66° to 4°
- Aperture
4 mm: F1.6
5.9 to 135.7 mm: F1.6to F4.1
- Illuminator
- Built-in Supplement Light TypeIR light
- IR Wavelength850 nm
- Video
- Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Sub-Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 20 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Third Stream
50 Hz: 25 fps (1280 × 720, 704 × 576)
60 Hz: 20 fps (1280 × 720, 704 × 576)
- Video Compression
Main stream: H.265/H.264/MJPEG,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 32 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- PTZ
- Pan SpeedConfigurable, 1°~128°/s, preset speed: 128°/s
- Pan Range360° infinite rotation
- Preset256 preset positions
- Tilt SpeedConfigurable, 1°~62°/s, preset speed: 70°/s
- Tilt Range-90°~90°
- Network
- ProtocolsTCP/IP,HTTP,DHCP,DNS,RTP,RTSP,NTP,HTTPS,SNMP,802.1X
- Image
- Image Parameters SwitchSupported
- Image SettingsSaturation,Brightness,Contrast,Sharpness,Gain,White balance,AGC
- Day/Night SwitchDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)
100dB
- SNR≥ 60 dB
- Image EnhancementBLC,HLC,3D DNR
- Interface
- On-Board StorageBuilt-in memory card slot, supporting TF card, up to 1TB
- Aviation PlugSupported
- Road Traffic and Vehicle Detection
- Smart Function
1.Road Diseases Detection (Recommended for sunny daytime use only):
Pothole;Waterlogging;Alligator Cracking;Patching;Pitted Skin;Transverse Cracking;Longitudinal Cracking;Manhole Frame Difference.
2.Smart Mode (Recommended for daytime use only):
Support license plate capture and recognition, Without helmet detection，Manned Non-Motor Vehicle.
3.Vehicle Evidence Capture (Recommended for daytime use only):
Support license plate capture and recognition, Without helmet detection，Manned Non-Motor Vehicle, Driving on the Lane Line, Wrong-Way Driving, Motor Vehicle on Non-Motor Vehicle Lane, Restricted Lane Occupation.
4.Stopped Vehicle Capture (Recommended for daytime use only):
Support vehicle parking violation detection.
5.Face capture&Face comparsion:
Support Face capture and comparsion.
- LPR Countries/Regions
Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,
Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,
Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,
America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,
Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,
Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- Accuracy (Under recommended installation and lighting conditions)
Capture rate > 90%,
LPR accuracy > 95%,
Mistaken capture rate < 10%
- Blocklist and Allowlist
Supported
- Face Detection
- Face CaptureSupported
- Face ComparisonSupported
- General
- Operating SystemLinux
- Power
DC 8 V to 36 V, 6.25 A, max. 50 W
- Material
Aluminum alloy
- Dimension344 mm × 251.6 mm × 360 mm (13.54″ × 9.9″ × 14.17″) (L × W × H)
- Package Dimension415 mm × 317 mm × 445 mm (16.34″ × 12.48″ × 17.52″) (L × W × H)
- Weight Approx. 11.3 kg (24.9 lb.)
- With Package WeightApprox. 14.6 kg (32.2 lb.)
- Operating Condition-35 °C to 65 °C (-31 °F to 149 °F). Humidity 95% or less (non-condensing)
- Storage Condition-35 °C to 65 °C (-31 °F to 149 °F). Humidity 95% or less (non-condensing)
- Approval
- EMC
CE-EMC: EN 50130-4:2011+A1:2014;EN 55032:2015+A11:2020+A1:2020;EN 61000-3-3:2013+A1:2019+A2:2021;EN IEC 61000-3-2:2019+A1:2021+A2:2024
- Safety
CB: IEC 62368-1: 2014,CB: IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014+A11: 2017,
CE-LVD:EN IEC 62368-1:2020+A11:2020
