Mobil Ağıllı Panoramik Mövqeləndirmə Sistemi
Mobil Ağıllı Panoramik Mövqeləndirmə Sistemi
Sorğu əsasında
Qiymət sorğusu- Camera
- Max. Resolution1920 × 1080
- Image Sensor1/2.8″ Progressive Scan CMOS
- Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON)
- Shutter Time1/25 s to 1/20000 s
- Lens
- Focal Length & FOV
4 mm, horizontal FOV 91°, vertical FOV 75°, diagonal FOV 105°
- Focus Fixed
- Iris TypeFixed iris
- ApertureMax. F2.0
- Illuminator
- Built-in Supplement Light TypeWhite light
- Light Bead4
- Built-in Supplement Light RangeUp to 8 m
- Video
- Main Stream
50 Hz:25fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Sub Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Video Compression
H.264 and H.265 encoding
Main stream: H.265/H.264/MJPEG
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeMain Profile,Baseline Profile,High Profile
- H.265 TypeMain Profile
- Network
- ProtocolsTCP/IP,HTTP,FTP,DHCP,DNS,RTP,RTSP,NTP,ISUP
- Wireless (Wi-Fi)
- Encryption ModeWPA-PSK/WPA2-PSK
- Wi-Fi Protocol
802.11b,802.11n,802.11g
- Frequency Range2.4 GHz to 2.4385 GHz
- Channel Bandwidth 20/40 MHz
- Modulation802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps), BPSK(1Mbps),,802.11g: OFDM,802.11n: OFDM
- Transfer Rate
11b: 11,5.5,2,1 Mbps,
11g: 54,48,36,24,18,12,9,6 Mbps,11n: up to 150 Mbps
- Wireless RangeUp to 120 m (The performance varies based on actual environment.)
- Antenna 1 antenna(s)
- Wireless (Mobile Communication)
- Frequency
EU:
LTE FDD: Band 1/3/5/7/8/20/28
LTE TDD: Band 38./40/41
WCDMA/HSPA+: Band 1/5/8
TD-SCDMA: Band 34/39
GSM/GPRS/EDGE: 850/900/1800MHz
LA:
LTE-FDD: Band1/2/3/4/5/7/8/12/17/28/66
LTE-TDD: Band38/40
WCDMA: Band1/2/3/4/5/8
GSM: 850/900/1800/1900MHz
- StandardLTE-TDD,LTE-FDD,TD-SCDMA,EVDO,EDGE,GPRS,GSM,CDMA
- SIM Card TypeNano SIM
- Supplement Detection (Satellite Positioning)
- Satellite PositioningGPS
- Interface
- Ethernet Interface1 RJ45 10M/100M/1000M self-adaptive Ethernet port(s)
- On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card, up to 512 GB
- Audio1 output (line out), max. output amplitude: 1.8 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Alarm 1 input(s),1 output(s)
- RS-4851 RS-485
- RS-2321 RS-232
- Power Output5 VDC, max. 2 A
- Road Traffic and Vehicle Detection
- Trigger ModeVideo trigger
- Smart Function
License plate recognition
- LPR Countries/Regions
Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,
Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,
Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,
America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,
Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,
Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- Accuracy (Under recommended installation and lighting conditions)
Capture rate > 98%,
Vehicle moving direction recognition accuracy > 98%,
LPR accuracy > 98%,
Mistaken capture rate < 2%
- Blocklist and AllowlistMax. 200000 records
- General
- Operating SystemLinux
- Power
DC 9 V to 36 V, 2.5 A, max. 22.5 W
- Material
Camera: aluminum alloy,
Host: aluminum alloy
- Dimension
Camera：Ø 38mm ×59.3mm (Ø 1.49 ×2.33 “),
Host：170mm×100mm×39.5mm(6.69 × 3.94″ × 1.56″) (L × W × H);”
- Package Dimension374 mm × 345 mm × 90 mm (14.72″ × 13.6″ × 3.54″) (L × W × H)
- Weight
Host: Approx. 0.58 kg (1.28 lb.);,
Camera: Approx. 0.14 kg (0.31 lb.)
- With Package WeightApprox. 1.82 kg (4.0 lb.)
- Operating Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
- Storage Condition-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General FunctionHeartbeat, password protection, NTP time adjustment
- Language
English
- Approval
- RFCE-RED:EN 301489-1 V2.2.3, EN 301489-3 V2.1.1, EN 301489-17 V3.2.4，EN 301489-52 V1.2.1，EN 300440 V2.1.1, EN 302288-2 V1.6.1
- EMCCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
- SafetyCB: IEC 62368-1: 2014,CB: IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014+A11: 2017,CE-LVD: EN IEC 62368-1:2020 +A11:2020
- EnvironmentCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
- Protection
IP67: IEC 60529-2013(only for camera)
