Запрос цены- General
- Dimension (W × H × D)280 × 179 × 45
- Storage Temperature-20℃-70℃
- Storage Humidity5%-95%
- Operating Temperature0℃-50℃
- Operating Humidity10%-90%
- Power SupplyAC: 100 V-240 V, 50 Hz±10%
- Power Consumption140 W(POE 125 W)＜15 W
- Network Parameters
- Switching Capacity10 Gbps
- Packet Forwarding Rate5.6 Mpps
- Software Function
- QoSFlow classification based on L2~4 protocols (S2108POE does not support the function.),CAR flow limit,802.1P/DSCP priority re-labeling (S2108POE does not support the function.),SP, WRR, and “SP+WRR”,Congestion avoidance mechanisms like Tail-Drop and WRED,Flow monitoring and flow shaping
- ReliabilityStatic/LACP link aggregation, EAPS and ERPS
- MulticastIGMP v1/v2/v3, IGMP snooping, IGMP Fast Leave, Multicast group strategy and quantity limitation, Multicast flow copying over VLANs (S2108POE does not support the function.)
- Management MethodConsole, Telnet, SSH2.0, Web; SNMP v1/v2/v3; TFTP, RMON
- PoE Power Supply
- PoE Port8 × 10/100Mbps RJ45 ports, 2 × Gigabit combo ports
- PoE StandardIEEE 802.3af, IEEE 802.3at
- PoE Power Pin1/2 (+), 3/6 (-)
- Approval
- EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 26)
- SafetyUL (UL 62368-1); CB (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2036)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2025)
