Запрос цены- General
- Dimension (W × H × D)442.5 × 350 × 44
- Storage Temperature-20℃-70℃
- Storage Humidity5%-95% non-condensing
- Operating Temperature0℃-45℃
- Operating Humidity5%-95% non-condensing
- Power SupplyAC：100V-240V，50Hz±10%
- Power Consumption＜55 W
- Network Parameters
- Port Number24 × gigabit RJ45 ports, 24 × gigabit fiber optical ports, and 8 × 10G SFP+ ports
- MAC Address Table64 K
- Switching Capacity256 Gbps
- Packet Forwarding Rate136 Mpps
- MAC exchangeSupport 64K MAC address table;
Support to view and remove MAC addresses
Support MAC address aging time configurable
Support MAC Sticky based on port constraint MAC address learning and dynamic binding MAC
Supports static, dynamic, and black hole MAC table entries.
Support source MAC address filtering
- Software Function
- Management MethodConsole, Telnet, SSH2.0, Web
SNMP v1/v2/v3
TFTP
RMON - QoSIt supports speed limit on port direction and direction.
Supports 8 priority queues per port.
Support mapping from message 802.1p to different queues
Support SP, WRR and SP+WRR algorithm
Support for message priority and message redirection
Support L2 (Layer 2) ~L4 (Layer 4) packet filtering function, provide source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP protocol source/destination port number, protocol, VLAN packet filtering function
Support functions based on queue speed limit and port shaping. - VLANSupport IEEE 802.1Q (VLAN), the whole machine supports 4K VLAN.
Support GVRP
Support QinQ
Support VLAN based on MAC/ protocol /IP subnet / policy / port
Support Private VLAN
Support 1:1 and N:1 VLAN Mapping functions - ReliabilitySupport STP (IEEE 802.1d), RSTP (IEEE 802.1w) and MSTP (IEEE 802.1s) protocol.
Support EAPS (Ethernet loop protection protocol) and MEAPS (fast ring network protection protocol).
Support FlexLinkLite tree topology protection mechanism to provide millisecond protection for primary and secondary links.
Support BPDU protection, root protection and loopback protection.
Support VRRP
Support GR for OSPF, BGP
Support BFD for OSPF, BGP - SecuritySupport 802.1x, support single port maximum user number limit
Storm suppression
Filter
User level management and password protection
Support AAA authentication, support Radius, TACACS+ and many other ways.
Support 802.1X authentication, support MAC authentication, and support MAC bypass authentication.
Support to prevent DOS, ARP attack function, ICMP anti attack
Support binding of IP, MAC, port and VLAN
Support MAC address learning limit
Support DHCP Snooping
Support port isolation, Sticky MAC
Support MAC address filtering
Support SSH V2.0
Support multicast, broadcast and unknown unicast message suppression
Support CPU protection function - MulticastSupport IGMP v1/v2/v3 Snooping and fast leave mechanism
Supporting multicast forwarding in VLAN and multicast multi VLAN replication
Multicast load sharing supporting bundled ports
Support controllable multicast
Port based multicast traffic statistics
Support IGMP v1/v2/v3, PIM-SM, PIM-DM, PIM-SSM - MCESupported
- MPLS VPNLDP protocol
P/PE of MPLS VPN
MPLS TE
MPLS OAM - IPv4Static Routing, RIPv1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, Routing Strategy
- IPv6Support ND (Neighbor Discovery)
Support PMTU
Support Ipv6 Ping, Ipv6 Tracert, Ipv6 Telnet
Support ACL based on source Ipv6 address, destination Ipv6 address, four port, protocol type, and so on.
Support MLD v1/v2snooping (Multicast Listener Discovery snooping) - VirtualizationSupport VSS virtualization technology
- Approval
- EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 25)
- SafetyUL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2035)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2024)
