Hikvision DS-3E3752-SI-48F4X

Артикул: HC-DS-3E3752-SI-48F4X

Hikvision DS-3E3752-SI-48F4X — 48 GE SFP, 4 10GE SFP+ коммутатор

Dimensions (W × H × D): 442.0 mm × 44.0 mm × 283.3 mm (17.7» × 1.73» × 11.15»)
Net Weight: 3.98 kg (8.77 lb)
Gross Weight: 5.69 kg (12.54 lb)
Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
Operating Humidity: 5% to 95% (no condensation)
Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
Relative Humidity: 5% to 95% (no condensation)
Installation Mode: Rack-Mounted (1U height, 19-inch width)

Быстрая доставка

После подтверждения наличия
По Азербайджану 1-2 дня

Официальная гарантия

до 36 месяцев
от производителя

100% оригинал

Официальный дистрибьютор Hikvision

Тех. поддержка

Помощь в подборе и настройке оборудование

Уточняйте наличие

По запросу

Купить в рассрочку

Цена для партнеров

Запросить скидку

Помощь специалиста

Сравнить

Затрудняетесь в выборе оборудования?

General
Dimensions (W × H × D)442.0 mm × 44.0 mm × 283.3 mm (17.7» × 1.73» × 11.15»)
Net Weight3.98 kg (8.77 lb)
Gross Weight5.69 kg (12.54 lb)
Operating Temperature0 °C to 45 °C (32 °F to 113 °F)
Operating Humidity5% to 95% (no condensation)
Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
Relative Humidity5% to 95% (no condensation)
Installation ModeRack-Mounted (1U height, 19-inch width)
Power Supply MethodAC: 100-240 V, 50/60 Hz, 2.1 A
Console Port2 × Console Port
USB Port1 × USB 2.0 Port
Management PortSupport management port.
Power Supply Unit1 fixed PSU(s)
Fan2 fixed fan(s)
Power Consumption≤ 150 W
Surge Protection10 kV
Packing ListSwitch × 1
AC Power Cord × 1
L-Shaped Bracket Kit × 1
Console Port Cable × 1
Grounding Cable × 1
Clip × 1
Plastic Foot × 4
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1

Network Parameters
Ports48 × Gigabit fiber optical port,4 × 10G fiber optical port
Switching Capacity216 Gbps
Packet Forwarding Rate160.7 Mpps
MAC Address Capacity32 K
Cache16 Mbits

Software Function
Link AggregationSupport static link aggregation.,Support dynamic LACP.
Auto-NegotiationFiber optical ports 1 to 48: 1G/100M auto-negotiation,Fiber optical ports 49 to 52: 10G/1G auto-negotiation
VLANSupport port-based VLAN.
Support IP subnet-based VLAN.
Support protocol-based VLAN.
Support MAC-based VLAN.
Support Private VLAN.
Support Super VLAN.
Support MVRP/GVRP.
Support VLAN Mapping.,4K VLAN
MulticastSupport IGMP Snooping.
Support MLD Snooping.
Support IGMP.
Support PIM.
Support PIMv6.
Support MLD.
STPSupport STP.
Support RSTP.
Support MSTP.
ERPSSupport G.8032 ERPS.
RRPPSupport RRPP.
Private Loop DetectionSupport loop detection.
Storm ControlSupport storm control.
Traffic SuppressionSupport traffic suppression.
MirroringSupport local port mirroring.
Support remote port mirroring.
Support N:1 port mirroring.
Support traffic mirroring.
IPv4 ServiceSupport Ping.
Support Telnet.
Support Trace.
Support DNS.
Support ARP.
Support ARP Proxy.
IPv4 RouteSupport IPv4 static routing.
Support OSPFv2.
Support RIPv1/v2.
Support BGP.
Support IS-IS for IPv4.
Support equal-cost multi-path (ECMP) routing.
Support policy-based routing.
Support VRRP for IPv4.
Support BFD for IPv4.
Support FRR.
IPv6 ServiceSupport IPv4 and IPv6 dual stacks.
Support Ping6.
Support Telnet over IPv6.
Support FTP over IPv6.
Support TFTP over IPv6.
Support Traceroute6.
Support neighbor discovery (ND).
Support PMTU discovery.
Support IPv6 tunnels.
Support GRE tunnels.
IPv6 RouteSupport IPv6 static routing.
Support OSPFv3.
Support RIPng.
Support BGP4+.
Support IS-IS for IPv6.
Support ECMP routing.
Support VRRP for IPv6.
Support BFD for IPv6.
Support FRR.
DHCPSupport DHCP client.
Support DHCP snooping.
Support DHCP snooping Option 82.
Support DHCP relay.
Support DHCP relay Option 82.
Support DHCP server.
Support DHCPv6 client.
Support DHCPv6 snooping.
Support DHCPv6 relay.
Support DHCPv6 server.
Cable TestSupport device link detection protocol (DLDP).
RADIUS AuthenticationSupport RADIUS authentication.
TACACS+ AuthenticationSupport TACACS+ authentication.
802.1X AuthenticationSupport 802.1X authentication.
MAC AuthenticationSupport MAC authentication.
Portal AuthenticationSupport portal authentication.
ACLSupport L2-L4 packet filtering functionality.
Support ACL definitions based on source and destination MAC addresses, source and destination IP addresses (IPv4/IPv6), IP protocol type, TCP/UDP port numbers or port ranges, and VLAN IDs.
Support Time Range-based ACLs.
Support configuration of basic, advanced, and MAC ACLs.
Support ACL application by port, VLAN, or globally. Support Expert ACL functionality.
Support inbound and outbound ACL enforcement.
QoSSupport 802.1p/DSCP priority mapping.
Support queue scheduling mechanisms (SP, WRR, SP+WRR).
Support queue scheduling mechanisms (WFQ, SP+WFQ).
Support WRED.
Support packet priority marking and remarking.
Support flow-based packet filtering.
Support flow-based traffic statistics.
Support flow-based packet redirection.
Support flow-based rate limiting.
Support 8 queues per port.
Support tail drop congestion control policy.
SecuritySupport DoS attack protection.
Support CPU attack protection.
Support IP Source Guard (IPv4/IPv6).
Support port isolation.
Support HTTPS.
Support ARP detection.
Support ARP source suppression.
Support ARP attack protection.
Support ND snooping.
Support IP-MAC binding.
Support port security.
NQASupport NQA.
LLDPSupport LLDP and CDP.

Operation Management
Topology DisplaySupport topology display.
Status AlarmSupport status alarm.
Management PlatformSupport device management via web.
Support SADP.
Support device management via Hik-Partner Pro.
Support device management via Hik-Central Pro.
Support device management via iVMS-4200 Client.
Support device management via Unified Network Management Platform.
SSHSupport SSHv2.
TelnetSupport Telnet.
SNMPSupport SNMPv1.
Support SNMPv2c.
Support SNMPv3.
NTPSupport NTP.
RMONSupport RMON.
sFlowSupport counter sampling.
FTPSupport FTP.
TFTPSupport TFTP.
CFMSupport CFM.
EFMSupport EFM.
Y.1731Support Y.1731.
DDMFiber optical ports support DDM.
LogSupport system logs.
