По запросу
Запрос ценыBarrier Housing Material | SGCC |
Barrier Housing Thickness | 2.0 mm |
Barrier Housing Door Thickness | 1.5 mm |
Barrier Housing Color | Orange |
Barrier Housing Door Color | Orange |
Boom Pole Installation Height | 880 mm |
Body Indicators | without indicator |
Matched Boom Pole Type | Folding pole: 1.5+1.5 m, 2+2 m, 2.5+2.5 m |
Boom Pole Direction | right by default, direction switchable |
Boom Pole Falling Delay | 10 s by default (configurable), min. 10 s (every 10 s followed a gap) |
Motor Type | DC brushless motor |
Number of Cycles | 5000000 |
Working Voltage | 220 VAC ± 15% |
Remote Controller Frequency | 433 MHz |
Current | 1.5 A |
Consumption | 300 W |
Temperature and Humidity | -30 °C to 70 °C (-22 °F to 158 °F) |
Rising Boom Pole for Poweroff | Optional, not supported by default |
Barrier Housing Dimensions(L × W × H) | 1248 × 486 × 480 mm (49.1 × 19.1 × 18.9 inch) |
Body Weight | 59.3 ± 5 kg (130.7 ± 11.0 lb.) |
Body Dimensions (with Package, Without Boom Pole)(L × W × H) | 1266 × 504 × 626 mm (49.84 × 19.84 × 24.65 inch) |
Boom Pole Length | 1.5+1.5 m;2+2 m;2.5+2.5 m |
Rising Speed | 1.5+1.5 m: 0.9S(Default) Adjustable 0.9S, 1.2S, 2S;2+2 m: 1.5S(Default) Adjustable 1.5S, 2S, 2.5S;2.5+2.5 m: 4S(Default) Adjustable 4S, 5S, 6S |
Falling Speed | 1.5+1.5 m: 3S(Default) Adjustable 1.5S, 2S, 3S;2+2 m: 3.5S(Default) Adjustable 2.5S, 3S, 3.5S;2.5+2.5 m:6S(Default) Adjustable 4S, 5S, 6S |
Duty Cycle | 100% |
Rising to Limit | 1 group |
Falling to Limit | 1 group |
Open | 1 group |
Close | 1 group |
Stop | 1 group |
IR/Inductive Loop/Radar | 1 group |
RS-485 | 1 group |
Traffic Signal Light | 1 group, external power supply required, max. 220 VAC supported |
Network | 1 group (reserved) |
Boom Pole Type | Curved boom pole |
Barrier Gate Series | 5 series |
Working Temperature & Humidity | -30 °C to 70 °C (-22 °F to 158 °F) |
Power Supply | 220 VAC ± 15% |
Working Current | 1.5 A |
Working Consumption | 300 W |
Package Size | 1,248 × 486 × 480 mm (49.1 × 19.1 × 18.9 inch) |
Weight | 59.3 ± 5 kg (130.7 ± 11.0 lb) |
Color | Orange |
RF | CE-RED;EN 300220-1 V3.1.1;EN 300220-2 V3.1.1;EN 301489-1 V2.2.3;EN 301489-3 V2.1.1;EN IEC 62311: 2020 |
EMC | CE-EMC：;EN 55032: 2015 + A11: 2020 + A1: 2020,;EN IEC 61000-3-2: 2019 + A1: 2021,;EN 61000-3-3: 2013 + A1: 2019 + A2: 2021,;EN 50130-4: 2011 + A1: 2014 |
Security | CE-LVD:;EN 62368-1: 2014 + A11: 2017;CB:;IEC 62368-1: 2014;IEC 62368-1: 2018 |
Environment | ROHS |
Protection | IP54 |
Boom Pole Type | folding pole |
Boom Pole Material | AL6061 |
Boom Pole Weight | 1.5 + 1.5 m: 5 ± 0.3 kg (11.02 ± 0.66 lb.);2 + 2 m: 6.35 ± 0.3 kg (14 ± 0.66 lb.);2.5 + 2.5 m: 7.45 ± 0.3 kg (16.42 ± 0.66 lb.) |
Boom Pole Color | White background with red bar |
Boom Pole Dimensions (with Package) | 1.5 + 1.5 m: 220 × 90 × 1720 mm (8.66 × 3.54 × 67.71 inch);2 + 2 m: 220 × 90 × 2220 mm (8.66 × 3.54 × 87.4 inch);2.5 + 2.5 m: 220 × 90 × 2720 mm (8.66 × 3.54 × 107.09 inch) |
Boom Pole Weight (with Package) | 1.5 + 1.5 m: 5.46 ± 0.3 kg (12.04 ± 0.66 lb.);2 + 2 m: 6.63 ± 0.3 kg (14.62 ± 0.66 lb.);2.5 + 2.5 m: 8.0 ± 0.3 kg (17.64 ± 0.66 lb.) |
Boom Pole Dimensions | 1.5 + 1.5 m: 178 × 79 × 3065.5 mm (70.08 × 31.1 × 1206.89 inch) ;2 + 2 m: 178 × 79 × 4065.5 mm (70.08 × 31.1 × 1600.59 inch);2.5 + 2.5 m: 178 × 79 × 5065.5 mm (70.08 × 31.1 × 1994.29 inch) |
