4-портовый неуправляемый коммутатор Fast Ethernet POE
4-портовый неуправляемый коммутатор Fast Ethernet POE
По запросу
Запрос цены- General
- ShellMetal material
- Net Weight2.92 kg (6.44 lb)
- Gross Weight4.12 kg (9.08 lb)
- Dimensions (W × H × D)440.00 mm × 44.00 mm × 220.80 mm (17.30» × 1.70» × 8.70»)
- Operating Temperature0 °C to 45 °C (32 °F to 113 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply 100-240 VAC, 50/60 Hz, Max. 4 A
- Max. Power Consumption250 W
- Power Consumption in Idle25 W
- Installation ModeRack (equipped with mounting ears)
- Surge Protection6 kV
- Network Parameters
- Ports24 × Gigabit PoE port,2 × Gigabit fiber optical port
- MAC Address Table8 K
- Switching Capacity52 Gbps
- Packet Forwarding Rate38.69 Mpps
- Internal Cache4.1 Mbits
- PoE Power Supply
- PoE StandardIEEE 802.3af;IEEE 802.3at;
- PoE Power PinEnd-span: 1/2(-), 3/6(+)
- PoE PortPoE: Ports 1 to 24
- Max. Port Power30 W
- PoE Power Budget225 W
- Approval
- EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
- SafetyUL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
- Chemistry
CE-RoHS (201165EU);
WEEE (201219EU);
Reach (Regulation (EC) No.19072006)
