4-портовый неуправляемый коммутатор Fast Ethernet POE
4-портовый неуправляемый коммутатор Fast Ethernet POE
По запросу
Запрос цены- General
- ShellMetal material
- Net Weight1.90 kg (4.20 lb)
- Gross Weight2.65 kg (5.84 lb)
- Dimensions (W × H × D)335.0 mm × 44.5 mm × 226.0 mm (13.19» × 1.75» × 8.90»)
- Operating Temperature0 °C to 45 °C (32 °F to 113 °F)
- Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply100~240 VAC, 50/60 Hz, Max. 4 A
- Max. Power Consumption250 W
- Power Consumption in Idle20 W
- Installation ModeDesk-Mounted,Wall-Mounted
- Surge Protection6 kV
- Network Parameters
- Ports24 × 10/100 Mbps PoE port,1× Gigabit RJ45 port,1 × Gigabit combo
- MAC Address Table8 K
- Switching Capacity8.8 Gbps
- Packet Forwarding Rate6.55 Mpps
- Internal Cache4 Mbits
- PoE Power Supply
- PoE StandardIEEE 802.3af;IEEE 802.3at
- PoE Power Pin8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE PortPoE: Ports 1 to 24
- Max. Port Power30 W
- PoE Power Budget230 W
- Dialing Function
- Long Range
Ports 17 to 24 : up to 250 m.
Long range performance may vary depend on camera model or cable condition.
- Port Isolation
Ports 1to 24: port isolation mode to improve network security.
Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
- PoE WatchdogPorts 1 to 24: auto detect and restart the cameras that do not respond.
- Approval
- EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
- SafetyUL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
- Chemistry
CE-RoHS (201165EU);
WEEE (201219EU);
Reach (Regulation (EC) No.19072006)
