Hikvision DS-VP41D-C/HW5L

CPU

i5-12500， 3.00GHz,18MB Cache， 6 Cores,12 Threads

Memory

Standard Config：2 × 8GB UDIMM，3200MT/s;Scalability：4 × 32GB UDIMM

Hard Disks

Standard Config：1 × 1TB M.2 SSD;Scalability：1 × 4TB 3.5inch SATA HDD

Supported Operating Systems

Win10 multilingual version pre-installed

Graphic Card

Standard Config：UHD Graphics 770（intergrated in CPU）;Scalability：1 × Semi-high Independent graphics card（Please contact technical support for more info.）

PCIe Slots

1*PCIe 4.0 x16 Slot1*PCIe 4.0 x4 Slot

Type-C

1

USB 3.0

1（Front）+3（Rear）

USB 2.0

2（Front）+2（Rear）

Universal Audio Port

1

Ethernet Port

1 x LAN 10/100/1000

VGA

/（HDMI port can be used as VGA port）

HDMI

1

DP

3（DP port can be used as HDMI port）

Net Weight

5.63 kg (12.42 lb)

Gross Weight

6.72 kg (14.81 lb)

Dimension (W × H × D)

92.60 mm × 290.00 mm × 292.80 mm (3.65» × 11.42» × 11.53»)

Package Dimensions (W × H × D)

394.00 mm × 264.00 mm× 487.00 mm (15.51» × 10.39» × 19.17»)

Operating Temperature

5 °C to 45 °C (41 °F to 113 °F)

Storage Temperature

-40 °C to 70 °C (-40 °F to 158 °F)

Operating Humidity

20% to 80% (no condensation)

Storage Humidity

5% to 95% (no condensation)

Power Supply

300 W PSU，92% Energy efficiency，80 Plus Platinum

Form Factor

Tower SFF
