Qiymət sorğusu- Infrared Image
- Image SensorVOx Uncooled Focal Plane Arrays
- Resolution160 × 120
- Pixel Interval17 μm
- Response Waveband8 μm to 14 μm
- NETDLess than 40 mK (@25 °C, F# = 1.1)
- Focal Length1.8 mm
- Focus ModeAthermalized
- Field of View90° × 66.4° (H × V)
- IFOV9.44 mrad
- Image Frequency50 Hz:25 fps
- ApertureF 1.1
- Min. Focusing Distance0.1 m
- Optical Module
- Image Sensor1/5” Progressive Scan CMOS
- Resolution1600 × 1200
- Focal Length1.29 mm
- Min. Illumination0.04 Lux @ (2.4, AGC ON)，0 Lux with IR
- Field of View92.6° × 75.8° (H × V)
- ApertureF 2.4
- Image Display
- Image FusionFusion view of thermal view and overlaid details of the optical channel
- Digital Zoom2×, 4×
- General
- Menu language33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Power Supply10-30 VDC, Max. 5 W
PoE (802.3af, class 2) - Working Temperature and Humidity-20 °C to 50 °C (-4 °F to 122 °F)
95% or less - Protection levelIP 67
- Approx. 335 g (0.74 lb)
- Dimension56 mm × 38.8 mm × 110 mm (2.20″ × 1.53″ × 4.33″)
- Image
- Main StreamThermal channel: 25 fps (640 × 480)
Optical channel: 25 fps (1600 × 1200) - Sub StreamThermal channel: 25 fps (640 × 480)
Optical channel: 25 fps (1600 × 1200) - Image Enhancement3D DNR, EIS
- Image SettingRotate mode, brightness, contrast and AGC adjustable by client software or web browser
- Compression Standard
- Video Compression H.264 (Baseline/Main/High Profile) /MJPEG/H.265
- Video Bit Rate256 Kbps to 16 Mbps
- Smart Function
- Temperature Range-20 °C to 150 °C (-4 °F to 302 °F), 0 °C to 550 °C (32 °F to 1022 °F)
- Temperature AccuracyMax (± 2 °C, ± 2%)
- Temperature Measurement RulesDisplay Max. and Min. temperature in live view;
3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line).
- Network
- Alarm TriggerVideo tampering alarm, Network disconnected, IP address conflict, Illegal login, HDD full, HDD error
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- General FunctionOne-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Interface
- Communication Interface1, RJ45 Ethernet port
1, RS-485 interface - Alarm1 input, 1 output
- Thermographic Integration
- External Optics CorrectionSupport Thermal Optical Transmittance and Manual Input External Optics Temperature;
Support Calibration Coefficient calculation - Temperature Info. Of Thermographic RuleReal-time Output; Time Interval: 500 ms
- Temperature Info. of ImageReal-time Output; Default is 4 fps, 32 bit × 640 × 512 per frame; 16 bit and 32 bit are selectable
- Capture Thermal Graphic32 bit 160 × 120
- Metadata OutputMax. 25 fps (16 bit 160 × 120)
- System Function
- LightingYes
