Qiymət sorğusu- Infrared Image
- Image SensorVOx Uncooled Focal Plane Arrays
- Resolution160×120
- Pixel Interval17μm
- Response Waveband8μm to 14μm
- NETDLess than 40 mK (@25°C,F#=1.1)
- Focal Length1.8mm
- Focus ModeAthermalized
- Field of View90° × 66.4° (H × V)
- IFOV9.44 mrad
- Image Frequency25 hz
- ApertureF 1.1
- Min. Focusing Distance0.1 m
- Optical Module
- Image Sensor1/2.8” Progressive Scan CMOS
- Resolution1600 × 1200
- Focal Length2 mm
- Field of View92.6° × 75.8° (H × V)
- General
- Menu languageEnglish
- Power Supply10-30 VDC, Max. 4W
PoE (802.3af, class 2) - Working Temperature and Humidity-20 °C to 50 °C (-4 °F to 122 °F), humidity less than 95%
- Protection levelIP 67
- 56 mm × 38.8 mm × 110 mm (2.20″ × 1.53″ × 4.33″)
- DimensionApprox. 335 g (0.74 lb)
- Image
- Main StreamThermal channel: 25fps (640 × 480);Optical channel: 25fps (1600 × 1200)
- Sub StreamThermal channel: 25fps (640 × 480);Optical channel: 25fps (1600 × 1200)
- Image Enhancement3D DNR, EIS
- Image SettingRotate mode, brightness, contrast and AGC adjustable by client software or web browser
- Compression Standard
- Video Compression H.264 (Baseline/Main/High Profile) /MJPEG/H.265, H.264+, H.265+
- Video Bit Rate256 Kbps to 16 Mbps
- Smart Function
- Temperature Range-20°C to 150°C (-4°F to 302°F), 20°C to 350°C (68°F to 662°F)
- Temperature AccuracyMax (±2°C, ±2%)
- Temperature Measurement RulesDisplay Max. and Min. temperature in live view;
3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line).
- Network
- Alarm TriggerVideo tampering alarm, Network disconnected, IP address conflict, Illegal login, HDD full, HDD error
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- General FunctionOne-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Interface
- Communication Interface1 RJ45 Ethernet port, 1 RS-485 interface
- Alarm1 input, 1 output
- Thermographic Integration
- External Optics CorrectionSupport Thermal Optical Transmittance and Manual Input External Optics Temperature;
Support Calibration Coefficient calculation - Temperature Info. Of Thermographic RuleReal- time Output;
Time Interval: 500 ms - Temperature Info. of ImageReal-time Output; Default is 4 fps, 32bit × 640 × 512 per frame; 16 bit and 32 bit are selectable
- Capture Thermal Graphic32 bit 160 × 120
- Metadata OutputMax. 25 fps (16bit 160 × 120)
