- Camera
- Image Sensor1/2.5” Progressive Scan CMOS
- Min. Illumination0.01 Lux @ (AGC ON)
- Shutter Speed1/3 s to 1/100, 000 s
- Lens
- Focal LengthFixed focal lens, 3.35mm
- FOVHorizontal FOV: 108°
Vertical FOV: 56°
Diagonal FOV: 135° - Lens MountM12
- Max. ApertureF2.0
- Video
- Video Input5-channel video (default: 1 channel; extension: 4 channels)
- Main StreamCH1:
25fps 1080P 1920 × 1080 (default)
25fps 720P 1280 × 720
CH2~CH5:
25fps 720P 1280 × 720 (default) - Sub-StreamCH1:
25fps 720P 1280×720
25fps 480P 640×480 (default)
CH2~CH5:
25fps 480P 640×480 (default) - Video Compression H.264 (default)
H.265
- Audio
- Audio Input1-channel audio
- Audio Compression G711U (Default)
G711A
AAC - Built-in MicOmnidirectional pickup, frequency response 100-20000 Hz
- Built-in SpeakerMax 0.8 W, with adjustable volume, not less than 50 dB at 1 m distance
- Wi-Fi
- Wi-Fi ProtocolIEEE 802.11b/g/n
- Frequency Range2.4 GHz
- Mobile Communication
- SIM Card Slot1, Industry Micro SIM, Plug-in type
- Dial-upBaseline：
FDD-LTE: B1, B3, B5, B8
TDD-LTE: B38, B39, B40, B41
TD-SCDMA: B34, B39
UMTS: B1, B8
EV-DO: BC0
CDMA 1x: BC0
GSM/GPRS/EDGE: 900/1800 MHzAustralia：
FDD-LTE: B1, B3, B5, B7, B28
TDD-LTE: B40
UMTS: B1, B5Europe：
FDD-LTE: B1, B3, B5, B7, B8, B20
TDD-LTE: B40
UMTS: B1, B8
GSM/GPRS/EDGE: 900/1800 MHzLatin America：
FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B10, B28, B66
TDD-LTE: B38, B40, B41
UMTS: B1, B2, B4, B5, B8
GSM/GPRS/EDGE: 850/900/1800/1900 MHzWarning: The industrial SIM card (MP2) is required, and the ordinary SIM card (MP1) is prohibited. We are not responsible for any problem caused by the use of any ordinary SIM card.
- Image
- SNR40 dB
- Wide Dynamic Range (WDR)Supports Digital WDR
- Image SettingsAdjustable brightness, chroma, contrast, color saturation, and sharpness
- OSDDate, Time, GPS, Speed, etc.
- Interface
- USB Interface1, Mini USB 2.0, used for connecting to peripheral device
- Reset Key1, Pinhole button
- Alarm Input2
- RS-2321
- Satellite Positioning
- GPS Information DetectionBDS (BeiDou Navigation Satellite System)
GPS (Global Positioning System)
- Indicator
- IndicatorWi-Fi Status Indicator
Off: Wi-Fi AP closed
Low Frequency Flashing blue: Wi-Fi AP open but no APP connection
High Frequency Flashing blue: Wi-Fi AP open and APP connection normalNetwork Status Indicator (4G)
Off: No 4G signal
Steady white: 4G signal and the platform connection normal
Flashing white: 4G signal normal but no platform connectionRecording Status Indicator(REC)
Off: The built-in or extended camera stops / fails
Steady white: The built-in or extended camera is recording normally
- General
- SystemEmbedded Linux
- LanguageCurrently only supports English
*The language includes APP interface language and voice reminder. - Product Dimension124.0 mm × 82.0 mm × 33.0 mm (4.9″ × 3.2″ × 1.3″)
- Product WeightApprox. 300 g (0.7 lb.)
- Image formatJPEG
- Power Supply9 to16V , support 12/24V with the buck line
- Package Dimension223 mm×153 mm×63 mm (8.8″×6.0″×2.5″)
- Operating Temperature-20°C to 45°C (-4°F to 113°F)
- ProtectionIP4X
*The dash camera is non-waterproof - With Package WeightApprox. 600 g (1.3 lb.)
- Power Interface1, 8-pin BM Male Terminal
- SensorSix-axis G-Sensor
*Harsh acceleration, Harsh deceleration and Harsh cornering - Operating Humidity10% to 95% (non-condensing)
