- Video
- Main StreamCH1: 1920 × 1080 (default), 1280 × 720
CH2: 1920 × 1080(default), 1280 × 720
CH3: 1920 × 1080, 1280 × 720 (default) - Sub-StreamCH1: 1280 × 720 (Default), 640 × 480
CH2 to CH3: 640 × 480 (default) - Video Compression H.264 (Default) or H.265
- Video Bit RateMain Stream Bit rate
CH1: 4 Mbps,1 Mbps,512 Kbps configurable, default 4 Mbps.
CH2: 4 Mbps,3 Mbps,2 Mbps,1 Mbps,512 Kbps configurable, default 4 Mbps.
CH3:4 Mbps,3 Mbps,2 Mbps,1 Mbps,512 Kbps configurable, default 1 Mbps.
Sub-stream bit rate:
CH1: 2 Mbps,1 Mbps,512 Kbps,256 Kbps configurable,default 1 Mbps.
CH2 to 3: 1 Mbps,512 Kbps,256 Kbps configurable,default 512 Kbps. - Stream TypePS Stream
- Frame RateMain Stream
10 fps / 15 fps / 25 fps / 30 fps can be selected. The default frame rate of CH 1 and CH2 is 25 fps and that of CH 3 is 15 fps.
Sub-Stream
configurable at 10fps, 15fps, 25fps, 30 fps, default 15 fps. - Video Input3 video inputs (external)
- Wi-Fi
- Wi-Fi Protocol802.11 b/g/n
- Frequency Range2.4 GHz
- Antenna2.4 GHz
- Mobile Communication
- Mobile Communication Type4G
- FrequencyEurope:
LTE-FDD: B1, B3, B5, B7, B8, B20, B28Latin America:
LTE-FDD: B2, B3, B4, B5, B7, B8, B28, B66Warning: Industrial SIM cards should be used for the devices. We will not be responsible for any issue caused by using general SIM cards.
- SIM Card TypeNano SIM card
- SIM Card Slot1(plug-in type, support industrial-grade Nano SIM card)
- Dial-upSupport
- Interface
- Local StorageSupports one TF card. The maximum capacity of the TF card is 1TB.Class 10 or above TF card is recommended.
- Power Output1pcs
- Alarm Input2-Channel Alarm Input
- Satellite Positioning
- GPS Information DetectionGPS (Global Positioning System)
GLONASS (Global Navigation Satellite System)
- Event
- Basic Event Tamper Alarm
G-sensor Emergency Alarm - Advanced Driving Assistance System (ADAS)Lane Departure Warning (LDW)
- Smart EventHelmet Detection
One-handed Riding
- Indicator
- IndicatorRecording Status Indicator (REC)
Off: Extended camera stops / fails.
Solid blue: Extended camera is recording normally.
Flashing Blue: External Camera Recording Exception: Check TF CardNetwork Status Indicator (4G)
Off: No 4G signal;
Solid Blue: 4G signal and the platform connection normal.
Flashing Blue: 4G signal is normal, but no platform connection.
- General
- Product Dimension116 mm × 68 mm × 32.26 mm
- Product WeightApprox. 265g
- Power Supply9-36 V
- Power ConsumptionMax. 9w
- Storage Conditions-40°C to 85°C
- ProtectionIP67
- Language English, Turkish, Portuguese, Spanish
- Software ResetSupport
- Online UpgradeSupport
- Operating Temperature-30°C to 70°C
- Operating Humidity10% to 95% (non-condensing)
- Sensor3-Axis Gsensor
