- Camera
- Image SensorFront view: 1/2.8″ CMOS
Rear view: 1/2.8″ CMOS - Min. IlluminationFront view: 0.01 Lux
Rear view: support IR - Shutter SpeedFront view: 1/30 s
Rear view: 1/30 s
- Lens
- Focal LengthFront view: 3.19mm
Rear view: 3.11mm - FOVFront view:
HFOV: 111°
VFOV: 58°
DFOV: 134.5°Rear view:
HFOV: 105°
VFOV: 57.5°
DFOV: 124° - Lens MountFront view: M12
Rear view: M12 - Max. ApertureFront view: F2.0
Rear view: F2.25
- Illuminator
- IR Wavelength850nm
- Supplement Light TypeIR
- Video
- Main StreamCH1: 1920 × 1080 (default)
CH2: 1920 × 1080(default) - Sub-StreamCH1: 640 × 480(Default)
CH2: 640 × 480 (Default) - Video Compression H.264 (Default), H.265
- Video Bit RateMain Stream Video Bit Rate：
CH1: 8Mbps,4 Mbps (Default),2Mbps,1Mbps
CH2: 4Mbps,2 Mbps,1 Mbps (Default),512Kbps
Sub-Stream Video Bit Rate：
CH1: 512Kbps (Default),256Kbps
CH2: 512Kbps,256Kbps(Default) - Stream TypePS Stream
- Frame RateMain Stream Frame Rate：
10 fps, 15 fps, 25fps, 30 fps available. The default CH1 is 25 fps, and CH2 is 15 fps.
Sub-Stream Frame Rate：
10fps, 15fps, 25fps, 30 fps available, CH1-CH2 default 15 fps. - Video Input2-Channel Video
- Audio
- Audio Compression AAC/G711u (Default)/G711A
- Audio Bit RateG711U: 64 kbps (Default)
G711A: 64 kbps
AAC: 64 kbps - Audio Sampling RateG711U: 8kHz(Default)
G711A: 8kHz
AAC: 16kHz - Built-in MicSupport
- Built-in SpeakerSupport
- Audio Input1-Way, Built-In mic
- Wi-Fi
- Wi-Fi Protocol802.11 b/g/n/ax
- Frequency Range2.4 GHz
- Antenna2.4 GHz
- Mobile Communication
- FrequencyEurope:
LTE-FDD: B1, B3, B5, B7, B8, B20, B28Latin America:
LTE-FDD: B2, B3, B4, B5, B7, B8, B28, B66Warning: The device requires industrial SIM card. Normal SIM card is not allowed. We are not responsible for any problems caused by using any normal SIM card.
- SIM Card TypeNano SIM card
- SIM Card Slot2 (plug-in type, support industrial-grade Nano SIM card, dual-card single waiting)
- Dial-upSupport
- Image
- SNRFront view: 42dB
Rear view: 42dB - Wide Dynamic Range (WDR)Front view: Linear
Rear view: Linear - OSDDate, time, GPS latitude and longitude, speed, license plate, and channel name.
- Function
- bluetoothSupport, BLE5.2
- Interface
- Local StorageUp to 512GB
- AudioAudio Input：1-Way, Built-In mic
Audio Output：1-Way, Built-In Speaker - Reset Key1 (pinhole button)
Press (≥1 sec & < 5 sec) to reset the device to restart.
Press and hold the reset key (≥ 5 sec) to restore the default parameter settings. - Power Output1 (10pin BMW)
- TF Card StorageSupports 1 TF card (up to 512GB each). Class 10 or above are recommended.
- Satellite Positioning
- GPS Information DetectionGPS (Global Positioning System)
GLONASS (Global Navigation Satellite System)
GALILEO (Galileo satellite navigation system)
- Indicator
- IndicatorRecord Indicator:
Solid light: Recording normal.
Not on: Recording exception.4G indicator:
Solid light: 4G signal is normal. Platform connected.
Flashing: 4G signal is normal. Platform not connected.
Not on: No 4G signal.Wi-Fi Status Indicator:
Solid light: Wi-Fi AP is on. App is connected.
Flashing: Wi-Fi AP is on. APP is not connected.
Not on. Wi-Fi AP is off.
- General
- Product Dimension113 mm × 71 mm × 68 mm (including mounting bracket).
- Package Dimension137mmx119mmx108mm
- Product Weight217 g (with mounting bracket)
- With Package Weight380 g
- Power Supply9-36V
- Power ConsumptionMax: 6W
- Storage Conditions-40°C to 85°C
- ProtectionIP4X (not water-proof)
- LanguageEnglish, Turkish, Portuguese, Spanish, Russian
- Software ResetSupport
- Online UpgradeSupport
- SystemEmbedded System
- Operating Temperature-30 °C to 70°C
- Sensor3-Axis
- Parking monitoring
- Parking monitoringSupport
- Playback
- PlaybackSupport
- Preview
- PreviewSupport
