Hikvision DS-2DB4236I-CWX(T5/316L)
316L 2 MP 36x partlayışa davamlı varifokal Bullet kamera
316L 2 MP 36x partlayışa davamlı varifokal Bullet kamera
Sorğu əsasında
Qiymət sorğusu- Camera
- Image Sensor1/1.8″ progressive scan CMOS
- Max. Resolution1920 × 1080
- Min. Illumination
Color: 0.0005 Lux @ (F1.5, AGC ON)
B/W: 0.0001 Lux @ (F1.5, AGC ON)
- Shutter Speed1/1 s to 1/30,000 s
- Day & NightIR Cut Filter
- Zoom31 × optical, 16 × digital
- Slow Shutteryes
- Lens
- Focal Length5.9 mm to 182.9 mm, 31 × optical zoom
- FOV
Horizontal field of view: 58.5° to 2.4° (wide-tele)
Vertical field of view: 34° to 1.3° (wide-tele)
Diagonal field of view: 65.8° to 2.7° (wide-tele)
- Focussemi-auto,manual,auto
- ApertureF1.5
- Zoom SpeedApprox. 5.6 s (Optical Lens, Wide-Tele)
- PTZ
- Movement Range (Pan)360° endless
- Movement Range (Tilt)From 0° to 90° (Auto Flip)
- Pan SpeedPan speed: configurable from 0.1° to 100°/s, preset speed: 100°/s
- Tilt SpeedTilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
- Proportional Panyes
- Presets300
- Preset Freezingyes
- Patrol Scan8 patrols, up to 32 presets for each patrol
- Pattern Scan4 pattern scans, record time over 10 minutes for each scan
- Park ActionPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
- 3D Positioningyes
- PTZ Status Displayyes
- Scheduled TaskPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output
- Power-off Memoryyes
- Video
- Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720);
- Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video Bit Rate32 kbps to 16384 kbps
- H.264 TypeBaseline profile,Main profile,High profile
- H.265 Typemain profile
- Scalable Video Coding (SVC)yes
- Region of Interest (ROI)yes
- Target Croppingno
- Audio
- Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
- Audio Bit RateG.722.1: 16Kbps,G.711ulaw: 64Kbps, G.711alaw: 64Kbps,MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps, 192 kbps;
- Audio Sampling RateMP2L2: 16kHz, 32kHz, 48kHz,PCM: 8kHz, 16kHz,32kHz, 48kHz
- Environment Noise Filteringyes
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- Simultaneous Live ViewUp to 20 channels
- APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
- User/HostUp to 32 users. 3 levels: Administrator, Operator and User
- SecurityUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
- Network StorageNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
- ClientiVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
- Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+
- Image
- Image Parameters Switchyes
- Image Settingssaturation, brightness, sharpness, contrast
- Day/Night Switchauto
- Wide Dynamic Range (WDR)120 dB
- SNR＞52dB
- Defogyes
- Image EnhancementHLC/BLC/3D DNR/EIS/Regional Exposure/Regional Focus
- Privacy Maskup to 24 masks
- Interface
- Ethernet InterfaceRJ45, self-adaptive 10M/100M Ethernet port
- On-board Storagesupport microSD/microSDHC/microSDXC cards, up to 256 GB
- Audio1-ch audio input and 1-ch audio output
- Alarm7-ch alarm input and 2-ch alarm output
- RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive
- Event
- Basic EventMotion detection,video tampering alarm,alarm input and output,exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)
- Smart EventMotion detection,video tampering alarm,alarm input and output,exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)
- LinkageAlarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
- Smart Linkagemanual tracking,event tracking
- Deep Learning Function
- Face Capture
1. Detects up to 10 faces simultaneously
2. Uploads face with background and closed-up face pictures
3. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face
- General
- Power100 VAC to 240 VAC, Max.: 60 W
- DimensionΦ 281 mm × 405 mm（Φ 11″ × 15.9″)
- 22 kg (48.52 lb.)
- MaterialSUS316L with anti-corrosion surface spray treatment
- Operating ConditionTemperature: -40°C to 60°C (-40°F to 140°F)，Humidity: ≤ 95%
- Cable Length1.95 m (6.40 ft.)
- General Functionmirror,password protection,watermark,IP address filter
- Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
- SafetyUL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
- ProtectionIP68, 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
- Explosion-Proof ProtectionATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db;IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db
