Qiymət sorğusu- Video and Audio
- Analog Video Input
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input5MP, 4MP, 3MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
- AHD Input1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- Audio Input4-ch, green-pin interfaces (2.0 Vp-p, 1 KΩ)
- Audio Output1-ch, 3.5mm interface (Linear, 1 KΩ)
- Two-Way Audio1-ch, 3.5mm interface (2.0 Vp-p, 1 KΩ)
- Synchronous Playback4-ch
- Recording
- Video CompressionMJPEG (sub-stream)/H.265+/H.265/H.264+/H.264
- Encoding Resolution5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
- Frame Rate
Main stream:
5 MP@12fps/4 MP@15fps/3 MP@18fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 10 Mbps
- Dual-streamSupport
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Network
- Network ProtocolTCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS, ONVIF profile S
- Network Interface1, RJ45 10M/100Mself-adaptive Ethernet interface
- Auxiliary Interface
- SD Card1 Micro SD card slot, support Micro SD card
- Capacity8G Up to 128 GB
- Serial InterfaceRS-485 (half-duplex); RS-232
- Alarm In/Out4/2
- General
- Power Supply12 VDC, 1.25 A
- Consumption≤ 15W
- Working Temperature-10 °C to +55 °C (+144 °F to +131 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)114 × 165 × 48 mm(4.5 × 6.5 × 1.9 inch)
- ≤ 1.5 kg (3.3 lb)
