Qiymət sorğusu- Video and Audio
- HDMI Input
1-ch：
1024×768/60Hz、1280×720/60Hz、1280×1024/60Hz、1600×1200/60Hz、1920×1080/60Hz、2560×1440/60Hz、4K(3840×2160)/30Hz
- Audio Input
1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ) (LINE IN)
- VGA Input
1-ch：
1080P60、UXGA（1600*1200）P60、SXGA（1280*1024）P60、1440*900P60、1366*768P60、720P60、XGA（1024*768）P60、800*600P60
- Audio Output1-ch, 3.5mm interface (Linear, 1 KΩ)
- HDMI Loopback1-ch
- Two-Way Audio1-ch, 3.5mm interface (2.0 Vp-p, 1 KΩ) (using the audio input)
- Recording
- Video CompressionH.264/H.265
- Frame Rate1~25/30fps
- Encoding Resolution
3840×2160
2960×1664
2560×1440
1920×1536
1920×1080
1280×720
Auto
Custom
- Video Bitrate32 Kbps to 10 Mbps
- Audio CompressionAAC,G711.a,G711.u
- Network
- Network ProtocolTCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, RTSP, NFS, UPnP™, HTTPS, ONVIF profile ,ISUP
- Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
- Auxiliary Interface
- SD Card1 Micro SD card slot, support Micro SD card (Hot-swapping is not supported)
- Capacity16GB Up to 128 GB
- Serial InterfaceRS-485 (half-duplex)
- Alarm In/Out1/1
- General
- Power Supply12 VDC, 1.5 A
- Consumption≤ 24W
- Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)114 × 135 × 48 mm(4.5 × 5.3 × 1.9 inch)
- ≤ 0.5 kg (1.1 lb)
