Qiymət sorğusu- System
- MotorBrushless Motor
- MCBF≥ 5 million times
- BrakeNot support
- Door open duration5 to 60 sec
- dToF sensor4
- Video
- LensPrime Lens
- Video compression standardH.265
- Resolution2 MP
- WDRSupport
- Video standardPAL by default, support NTSC
- HOVHorizontal: 59°
Vertical: 108°
- Audio
- Audio compression standardG.711U
- Audio compression bitrate64 Kbps
- Audio outputSupport
- Volume adjustmentSupport
- Power output5.5W
- Network
- Wired networkSupport,10M/100M
- Wi-FiFor AP mode only
- Interface
- Network interface2
- Lock control0
- Exit button2
- Alarm output4
- RS-4854
- RS-2322
- Wiegand2
- USB2
- Fire alarm input2
- Case input2
- Hardware
- Access controllerSupplied
- SupercapacitorSupplied
- Network switchNot supplied
- Capacity
- Face capacity100,000
- Card capacity200,000
- Event capacity100,000
- Authentication
- Face recognition distance0 m to 2 m
- Face recognition accuracy rate＞99%
- Face recognition duration＜200 ms
- Card TypeM1 card
- Card reading frequency13.56 MHz
- Card reading distance3cm
- Card reading duration＜1s
- Function
- Configuration via PC WebSupport
- Configuration via mobile WebSupport
- Hik-ConnectSupport
- Multi-factor authenticationSupport
- Face anti-spoofingSupport
- Built-in face recognitionSupport
- Communication protocolISAPI
- KeyfobSupport, 433 MHz/868 MHz, within 50 m
- General
- Lane width550 mm to 950 mm (21.65″ to 37.4″)
- Barrier material8 mm acrylic glass
- Pedestal materialSUS304 stainless steel 1.2 mm
- IndicatorLane status indicator, authentication indicator and barrier light
- Power consumptionSide: Standby: 35W Working: 60W Peak: 80W; middle: Standby: 70W Working: 120W Peak: 160W
- Working temperature -15 °C to 65 °C (5 °F to 149 °F)
- Working humidity0% to 95% (No condensing)
- Protective levelIPX4
- DimensionsWithout package: 1200 mm × 170 mm × 1052 mm (47.2″ × 6.7″ × 41.4″)
With package: 1295 mm × 280 mm × 1125 mm (51.0″ × 11.0″ × 44.3″) - Net: 25 kg (55.1 lb)
Gross: 32 kg (70.5 lb) - Approval CE/CB/RoHS/REACH/WEEE
- Power supply methodM: 100-120V~/200-240V~,50Hz/60Hz,1.6A L/R: 100-240V~,50Hz/60Hz,0.8A
- LanguageEnglish, Japanese, Thai, Indonesian, Russian, Spain (European), Spain (Latin America), Portugal (Brazil), Arabic, Kazakh, Uzbek, Ukraine
- Interconnecting cable length5.5 m
- Configuration
- Lane width650;750;900
- Pedestal length1200 mm
- Module selectionNO
- Pedestal width170 mm
- Wall distance20 mm
- BaseNO
- Barrier materialAcrylic glass
- Application environmentIndoor
- Authentication modeCard;Face;QR code
- Card typeM1
- Recommended width650 mm
- Base modelNA
- Product typeSwing barrier
- Remote controller type433Mhz;868Mhz
- Built-in face recognitionYES
- Convert FaceNO
- Door HeightDefault(0.79m)
- Door wing gapDefault:50mm
- Integrated AuthFace;Card
