Qiymət sorğusu- System
- MotorBrushless motor
- MCBF≥ 3 million times
- IR light detectors4 pairs
- Interface
- Network interfaceNA
- Lock controlNA
- Exit button
Main: 2
Sub: 2
- Alarm outputNA
- RS-485NA
- RS-232NA
- Fire alarm input1
- Hardware
- Access controllerNot supplied
- Capacity
- Card capacityNA
- Event capacityNA
- General
- Throughput
20 to 60 persons per minute
The actual throughput is affected by the person passing rate and passing method.
- Lane width550 mm to 900 mm (21.65″ to 35.4″)
- Barrier material8 mm acrylic glass
- Pedestal materialSUS304 stainless steel
- Power consumption
Standby: 30 W
Working: 80 W
Peak: 120 W
- Working temperature -20 °C to 65 °C (-4 °F to 149 °F)
- Working humidity10% to 95% (No condensing)
- Dimensions
Without package: 1200 mm × 218 mm × 1023 mm (47.2″ × 8.6″ × 40.3″)
With package: 1300 mm × 320 mm × 1080 mm (51.2 × 12.6″ × 42.5″)”
Net:
Left: 33 kg (72.8 lb)
Middle: 43 kg (94.8 lb)
Right: 36 kg(79.4 lb)
Gross:
Left: 56 kg (123.5 lb)
Middle: 64 kg (141.1 lb)
Right: 60 kg (132.3 lb)
- Power supply method100 to 240 VAC, 50 to 60 Hz
- Configuration
- Lane width650;750;900
- Pedestal length1200 mm
- Module selectionYES
- Pedestal width170 mm
- Wall distance20 mm
- BaseNO
- Barrier materialAcrylic glass;Stainless steel pipe
- Application environmentIndoor and outdoor
- Authentication modeFace
- Recommended width650 mm
- Product typeSwing barrier
- Remote controller typeNA
- Movement Protrusion Width0
- Convert FaceNO
- Door HeightDefault(0.79m)
- Door wing gapDefault:44mm;950mm:70mm
