- System parameters
- Operation systemLinux
- ROM4 GB
- RAM1 GB
- ProcessorEmbedded high performance processor
- Video parameters
- Lens3
- ResolutionMain stream: 4MP(2688x1520P), 2MP(1920x1080P), 1MP(1280x720P)
Sub stream: 2MP(1920x1080P), 1MP(1280x720P), 0.3MP(640x480P) - FOVCenter Lens: Horizontal: 180°; Vertical: 105°
Side Lenses: Horizontal: 75°; Vertical: 150° - Wide dynamic range (WDR)Support 120 dB
- Supplement lightIR light, up to 3 m
- Video compression standardH.264; H.265; MJPEG
- Audio parameters
- Audio input4 built-in omnidirectional microphones
- Audio compression standardG.711u, G.711a, Opus, AAC-LD, AAC-LC, G.726, G.722.1, G.729
- Audio output2 built-in loudspeakers
- Audio compression bitrate8~64 Kps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Audio Performance50cm, 85dB
- Audio Sample Rate8kHz, 16kHz
- Capacity
- User capacity10000
- Face capacity10000
- Card capacity50000
- Sub door station capacity16
- Network parameters
- Network protocolTCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, IPv4, IPv6, UDP, WebSocket, WebSockets，ONVIF, SIP v2 (RFC3261)
- Wi-Fi2.4G
- BluetoothSupported, BLE 5.2
- 3G/4G/
- Wi-Fi ProtocolIEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax
- Wi-Fi TypeWiFi 6
- Authentication
- Authentication modeFace, Card, QR code, Bluetooth, Hik-Connect, Indoor station, Mobile APP
- Card typeM1 Card, Desfire
- Card reading frequency13.56 MHz
- Face recognition distance0.3 to 1.5 m
- Card reading distance3 cm
- Application
- Mobile APPHik-Connect
- Motion DetectionSupport
- PlaybackSupport
- Call ElevatorSupport
- Smart Features1. Sound Classification Detection: Scream, Glass Breaking Sound, Crying Sound, Gunshot
Recommended Detection Distance: ＜ 3 m
2. Portrait Centered
3. Perimeter Detection: Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection
Recommended Detection Distance: ＜ 10 m
Supports Person and Vehicle Target Detection
4. Fall Down Detection
Recommended Detection Distance: ＜ 5 m
5. Target Microphone
Pickup Range: Forward 60° Sector Area
Recommended Detection Distance: 0.5 m ~ 1 m
6. Smart Noise Reduction
Supports Common Steady-State and Non-Steady-State Street Noises
Noise Reduction Level: > 15 dB
- Device interfaces
- Alarm input4, (include Exit button and Door contact input)
- Network interface1 RJ-45, 10/100 Mbps self-adaptive
- TAMPER1
- Exit button2
- RS-4851
- USB/
- Wiegand/
- TF cardSupport TF card, up to 128 G
- Alarm output/
- Lock control2 relay, Max. 30 VDC 1A
- Door contact input2
- Supported TF FormatFAT32;exFAT
- General
- Application environmentOutdoor
- Button4 physical button(s)
- InstallationSurface mounting & Flush mounting
- Without package: 400 g (0.88 lb),With package: 788g (1.74 lb)
- Indicator3
- Protective levelIP66, IK08
- Storage temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working temperature-40 °C to 60 °C (-40 °F to 140 °F)
- Working humidity10% to 90% (no-condensing)
- Battery/
- Dimension (W × H × D)202.6 mm × 95.6 mm × 34 mm (7.98″ × 3.76″ × 1.34″)
- Power consumptionWith Lock: < 14 W
Without Lock: < 20 W - Power supply12 VDC, 2 A,IEEE 802.3 at, standard PoE
- MaterialRear Shell Material: Plastic
Front Shell: Aluminum Alloy & Plastic
Frame: Aluminum Alloy
Viewing Window Panel Material: Plastic - Power Supply OutputMax. 12 VDC, 500mA
- LanguageEnglish, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
- Ambient lightingSupport
