Hikvision DS-KV6133-WME1

Operation system

Linux

ROM

32 MB

RAM

256 MB

Processor

Embedded high performance processor

Screen size

/

Operation method

/

Type

/

Resolution

/

Lens

1

Resolution

Main stream: 1920 × 1080p，1280 × 720p;Sub stream: 1280 × 720p，640 x 480p

FOV

Horizontal:129°,Vertical: 75°

Wide dynamic range (WDR)

Support 120 dB

Supplement light

IR light, up to 2.5 m

Video compression standard

H.264

Audio input

1 built-in omnidirectional microphone

Audio compression standard

G722.1、OPUS、G711U、G711A、G726 、AAC_LC、 AAC_LD

Audio output

1 built-in loudspeaker

Audio compression bitrate

16/32/64 Kps

Audio quality

Noise suppression and echo cancellation

Volume adjustment

Adjustable

User capacity

2000

Face capacity

/

Card capacity

10000

Network protocol

TCP/IP, RSTP

Wi-Fi

2.4GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n

Bluetooth

/

3G/4G

/

Alarm input

4

Network interface

1 RJ-45, 10/100 Mbps self-adaptive

TAMPER

1

Exit button

/

RS-485

1

USB

/

Wiegand

/

TF card

1(Reserved)

Alarm output

/

Lock control

1 relay, Max. 30 VDC 2 A

Door contact input

1

Audio output

1 external loudspeaker(Reserved)

Button

1 physical button

Installation

Surface mounting, Flush mounting

Indicator

2

Weight

Net weight: 0.190kg Gross weight: 0.414kg

Protective level

IP65

Working temperature

-40 °C to 53 °C (-40 °F to 127.4 °F)

Working humidity

10% to 95% (no-condensing)

Dimension (W × H × D)

181.6 mm × 103.6 mm × 29.5 mm (7.1″ × 4.0″ × 1.1″)

Battery

/

Application environment

Outdoor

Power consumption

＜ 10 W

Language

English, Arabic, French (Europe), Russian, Spanish (Europe), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
