Сервер обнаружения дорожно-транспортных происшествий
Сервер обнаружения дорожно-транспортных происшествий
По запросу
Запрос цены- Camera
- Max. Resolution3840 × 2160
- Min. IlluminationColor: 0.001 Lux@(F1.4, AGC ON) , 0.0005 Lux with IR
- Shutter Time50 us-20000 us
- Lens
- Focal Length & FOV1550(default): CS-Mount, Horizontal: 42.7° to 13.7°, Vertical: 23.4° to 7.6°, Diagonal: 49.7 to 15.8°
5721: CS-Mount, Horizontal: 106.5° to 33.1°, Vertical: 60.2° to 18.7°, Diagonal: 121.4° to 37.8°
- Video
- Main Stream50 Hz: 25 fps (3840 × 2160, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (3840 × 2160, 1920 × 1080, 1280 × 720) - Sub Stream1920 × 1080, 704 × 576
- Video Compression H.264 and H.265 encoding
Main stream: H.265/H.264/MJPEG
Sub-stream: H.265/H.264/MJPEG - Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline profile/Main profile/High profile
- H.265 TypeBaseline profile/Main profile/High profile
- Network
- ProtocolsTCP/IP,HTTP,DNS,RTP,RTSP
- SecurityUsername and password authentication , HTTPS Digital certificate
- Web BrowserIE8-IE11, plug-in free live view supported
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.
- Day/Night SwitchAuto/Scheduled/Triggered by alarm in
- Image Enhancement3D DNR
- Interface
- Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interfaces；
1 1000 M fiber interface - On-board StorageBuilt-in microSD/TF card, up to 128 GB
- Alarm 1 output interfaces
- RS-4851 RS-485 interfaces (half duplex, HIKVISION)
- Event
- Basic EventHDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception
- Road Traffic and Vehicle Detection
- Coverage2 to 3 lanes
- Smart FunctionVehicle type, lane flow, lane speed, space headway, time headway, lane time occupancy rate, lane space occupancy rate, queuing length, and traffic status
Driving on lane line, lane change, wrong-way driving, stopped vehicle, Emergency lane occupation, roadblock, construction, fallen object, pedestrians, congestion, fire/smoke in tunnel detection
- General
- Power24 VDC ± 20%, PoE (802.3at, class 4)，24 W MAX
- DimensionWith package: 175.68 × 137.5 × 443.99 mm (6.92″ × 5.41″ × 17.48″)
- Weight approx. 6.5 ± 0.5 kg (14.3 ± 1.1 lb)
- Operating ConditionTemperature: -30 °C ~70 °C
Humidity: <95% - General FunctionHeartbeat, password protection, NTP time adjustment
- Approval
- ProtectionIP66
