Qiymət sorğusu- General
- Product Dimensions (W × H × D)97.07mm × 96.51mm × 200.0mm
- Package Dimensions (W × H × D)118mm × 118mm × 260mm
- Net Weight0.533kg
- Packing List3000Mbps Wi-Fi6 Router x 1
Power Supply Adaptor × 1
CAT5e Network Cable × 1
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1
Product Flyer×1 - Packing MethodSingle pack
- Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity10% to 90% RH non-condensing
- Storage Temperature5% to 95% RH non-condensing
- Storage Humidity-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Installation ModeDesk-Mounted
- Max. Power Consumption≤16 W
- Gross Weight0.785kg
- Wireless Parameter
- Wireless StandardIEEE 802.11a/n/ac/ax @5GHz
IEEE 802.11b/g/n/ax @2.4GHz - Working Frequency Band2.4GHz:2.4～2.4835GHz
5.1GHz:5.15～5.35GHz
5.8GHz:5.725～5.85GHz - Transmitting PowerCE:
＜20dBm(2.4GHz)
＜23dBm(5GHz) - Receiving Sensitivity2.4GHz：
-91dBm@11ax_40M—MCS0
-61dBm@11ax_40M—MCS115GHz：
-86dBm@11ac_80M—MCS0
-56dBm@11ax_80M—MCS11 - Antenna5 high gain antennas
- Wireless RangeUp to 1506 ft²/140 m²
（Recommend coverage for home use, actual Wi-Fi range varies depending on the layout and wall materials） - Max. Connections256
- Recommended Connections60
- Wireless FeaturesDual Band Supported,MU-MIMO Supported,Beamforming Supported,OFDMA Supported
- Antenna Gain2.4G:5 dBi
5G:5 dBi - Max. Wi-Fi Speed≤ 3000 Mbps
5GHz: 2402Mbps
2.4GHz: 574Mbps
- Hardware Parameter
- Network Interface4 × 10/100/1000M Mbps WAN/LAN Port
- LED IndicatorRed/blue/yellow for different working states, flashing mode
- Power Supply MethodPower Supply Adapter
- Power SpecificationsDC 12 V, 1.5 A
- ButtonReset button, WPS/MESH Button
- RAM256MB DDR3
- ROM128MB ( 1G ) NAND
- Software Function
- Security ModeWPA2-PSK,WPA/WPA2-PSK,WPA2-PSK/WPA3-SAE supported
- Security MechanismSupport fast and secure WPS connection
Support hiding wireless network name
Support controlling terminal network connection
Support firewalls
Login Authentication
VPN
Port Mapping
DMZ
UPNP - Management MethodWeb Control: PC, mobile
App Control: HPP, HC
TR069(TR098/TR181) - UpgradeWeb Upgarde
App Cloud Upgrade
Auto Upgrade - System LogSystem log
- Operating ModeRouter Mode
Access Point Mode
Wireless Extender Mode - WAN ModeDHCP
Static IP
PPPOE - IP VersionIPv4
IPv6 - Parental ControlURL Filtering
Time Controls
Wi-FI Schedule
Custom Pfofiles - FirewallForbid UDP flood attack,Forbid TCP SYNC flood attack,Forbid ICMP flood attack
- DDNSOray、NO-IP（https://www.noip.com/）、DynDNS（https://account.dyn.com）
- VPNPPTP Server,L2TP Server,OpenVPN Server,PPTP Client,L2TP Client,OpenVPN Client
- NAT ForwardingPort Forwarding
DMZ
UPnP - OthersVLAN/IPTV,IGMP,WAN Self-Adaption,Quick Diagnosis,WIFI Optimization,Ping/Tracert
- MESHHikvision Mesh
- Roaming802.11k/v
- DHCPDHCP Client List
DHCP Server
