Hikvision DS-3WAP6618-EI

Artikul: HC-DS-3WAP6618-EI

Hikvision DS-3WAP6618-EI — Wi-Fi 6 1800M çöl Access Point

Net Weight: 1.6 kg (3.53 lb)
Gross Weight: 5.64 kg (12.43 lb)
Working Temperature: -30°C to 65°C (-22°F to 149°F)
Working Humidity: 0% to 100% (condensation)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Storage Humidity: 0% to 100% (no condensation)
Product Dimensions (W × H × D): Ø240 mm × 200 mm (excluding bracket）
Packing List: 1800 M Access Point × 1, Screw Pack × 1, Installation Bracket × 1, Waterproof Cap × 1, Fiber Optic Converter Head × 1, Afety Rope × 1, Quick Start Guide × 1, Regulatory Compliance and Safety Information × 1

Mövcudluq təsdiqləndikdən sonra
Azərbaycan daxilində 1-2 gün

36 aya qədər
istehsalçıdan

Hikvision-un rəsmi distribyutoru

Avadanlıqların seçilməsi və qurulmasında köməklik

Mövcudluğu dəqiqləşdirin

Sorğu əsasında

Partnyorlar üçün qiymət

Endirim tələb edin

Mütəxəssis köməyi

Avadanlıq seçməkdə çətinlik çəkirsiniz?

General
Net Weight1.6 kg (3.53 lb)
Gross Weight5.64 kg (12.43 lb)
Working Temperature-30°C to 65°C (-22°F to 149°F)
Working Humidity0% to 100% (condensation)
Storage Temperature-40°C to 70°C (-40°F to 158°F)
Storage Humidity0% to 100% (no condensation)
Product Dimensions (W × H × D)Ø240 mm × 200 mm (excluding bracket）
Packing List1800 M Access Point × 1, Screw Pack × 1, Installation Bracket × 1, Waterproof Cap × 1, Fiber Optic Converter Head × 1, Afety Rope × 1, Quick Start Guide × 1, Regulatory Compliance and Safety Information × 1
Power Supply MethodDC power supply: 12 V, 2 A;
PoE power supply: IEEE 802.3at;
Installation ModeWall Mounting, Holding Pole (diameter 67-127 mm)
Power ConsumptionStandby Power Consumption: 5.5W
Typical Power Consumption: 15W
Maximum Power Consumption: 18W
Protection GradeIP68

Wireless Parameter
Wireless SpeedMax: 1775 Mbps;
2.4G: 574 Mbps;
5G: 1201 Mbps;
Wireless StandardWi-Fi 6
Working Frequency BandRadio 1: 5G (11a/n/ac/ax);
Radio 2: 2.4G (11b/g/n/ax);
Bandwidth2.4G: Auto/20/40 MHz;
5G: Auto/20/40/80 MHz;
Recommended Coverage RangeRecommended Coverage Radius: 150 meters.
Note: The signal coverage range is greatly affected by the environment. For example, walls, glass doors, and other obstacles will affect the signal coverage. The above – mentioned values are for reference only.
ModulationOFDM: BPSK @ 6/9 Mbps, QPSK @ 12/18 Mbps, 16-QAM @ 24 Mbps, 64-QAM @ 48/54 Mbps
DSSS: DBPSK @ 1 Mbps, DQPSK @ 2 Mbps, and CCK @ 5.5/11 Mbps
MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM and 1024-QAM
OFDMA
Max. Number of Connected Clients256
Recommended Number of Connected Clients100
Transmitting Power2.4G: Combined power: 28 dBm;
5G: Combined power: 30 dBm;
Note: The actual transmission power varies according to regulations in different countries and regions;
Wireless SecurityWPA2-PSK, WPA-WPA2-PSK, WPA3-PSK, WPA2-WPA3-PSK
Antenna2.4 GHz: 2 built-in omnidirectional antennas
5 GHz: 3 built-in omnidirectional antennas
Antenna Gain2.4 GHz: 4 dBi
5 GHz: 5.1 dBi
RF DesignDual-radio
4 spatial streams
2.4G: 2 × 2, MU-MIMO
5G: 2 × 2, MU-MIMO
FEM2.4 GHz: 2 x eFEM
5 GHz: 3 x eFEM

Software Features
Operation ModeAP mode (default);
Routing mode;
Wireless ManagementSupport wireless configuration;
Support RF configuration;
Support Health Mode;
Support guest SSID;
Support wireless 802.11k/v/r roaming;
Support wireless optimization;
Support wireless SSID speed limit;
Support wireless RF speed limit;
Support wireless intelligent speed limit;
Support wireless terminal speed limit;
Support weak signal access control;
Support weak signal to kick offline;
Support roaming sensitivity adjustment;
Support wireless access control;
Support wireless terminal association;
Support Band steering;
Support AP load balancing;
Supports airtime scheduling (ATF);
Support smart antenna technology (beamforming), improving the signal’s strength on clients;
InterfaceSupport uplink port VLAN;
Support MAC address modification;
Support LAN configuration;
Support Port VLAN;
IP ServicesSupport DHCP Client;
Supports DHCP Server;
Support LLDP;
Support SADP;
Service and SupportSupport NAT Traversal;
Support Audit Log;
Support Fault Diagnosis;
Support Fault Alarm;
Support One-Click Fault Collection;
Support Network Diagnostic Tools;
Support SSH;
Support Cloud Service Diagnosis;
Support Local Upgrade;
Support Online Upgrade;
Support Cloud Service;
Support App Management;
Support CAPWAP DTLS encryption;

Approval
EMCCE-EMC (EN 55032:2015/A1:2020 EN 55035:2017/A11:2020 EN IEC 61000-3-2:2019/A2:2024 EN 61000-3-3:2013/A2:2021 EN 50130-4:2011/A1:2014)
SafetyCB (IEC 62368-1: 2018), CE-LVD (EN 62368-1:2014/A11: 2017)
ChemistryCE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No.1907/2006)
RadioEN 50385, EN IEC 62311, EN 62311, EN IEC 62368-1, EN 301 489-1, EN 301 489-3, EN 301 489-17, EN 55032, EN 55035, EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4, EN 300 328, EN 301 893, EN 300 440
