Qiymət sorğusu- Thermal Module
- Image SensorVanadium Oxide Uncooled Focal Plane Arrays
- Resolution256 x 192
- Pixel Pitch12 μm
- NETD ≤ 40 mK(@25° C,F# = 1.0)
- Focal Length8 mm
- IFOV1.5 mrad
- Aperture F1.0
- Field of View23.7° × 17.8° (H × V)
- Min. Focusing Distance1.5 m
- Digital Zoom×2, ×4
- Optical Module
- Image Sensor1/2.7″ Progressive Scan CMOS
- Resolution2688 × 1520
- Min. Illumination0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
- Field of View39.4°(H) x22.1°(V)
- Focal Length8 mm
- Shutter Speed1 s to 1/100,000 s
- White BalanceMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
- Day & Night Mode IR Cut Filter with Auto Switch
- WDR120 dB
- Image Effect
- Bi-spectrum Image Fusion Display the details of optical channel on thermal channel
- Target Coloration Yes. Supported in white hot and black hot mode
- Illuminator
- IR Distance Up to 30 m
- IR Intensity and Angle Automatically adjusted
- Audible and Visual Alarm
- White Light Range Up to 30 m
- Visual Alarm
Yes. White light alarm with adjustable flashing frequencies
- Audio alarm
Yes, for three types of audible alarm (VCA and Temperature Exception)
3 preset voice alerts (one for each)
6 importable user-defined voice alerts (6 options shared in the two types)
- Smart Function
- VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
- Temperature Measurement3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
- Temperature Range-20°C to 150°C (-4°F to 302°F)
- Temperature Accuracy ± 8°C (± 14.4°F)
- Video and Audio
- Main Stream
Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-stream
Thermal:
25 fps (704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
- Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
- Audio CompressionG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
- Network
- Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
- Network StorageMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
- Simultaneous Live ViewUp to 20 channels
- User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
- Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
- Client iVMS-4200, Hik-Connect
- Mobile Communication
- SIM Card TypeMicroSIM
- Frequency
LTE FDD: B 1/3/5/7/8/20/28
LTE TDD: B 38/40/41
WCDMA: B 1/5/8
- StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
- Interface
- Alarm Input2, alarm input (0-5 VDC)
- Alarm Output 2, alarm output (alarm response actions configurable)
- Alarm ActionLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
- Audio Input
1, 3.5 mm Mic in/Line in interface
Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
- Audio OutputLinear level, impedance: 600 Ω
- Communication Interface
1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface (half duplex)
- General
- Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
- Power Supply
12 VDC ± 25%, φ 5.5 mm coaxial power plug
PoE (802.3af, class 3)
- Power Consumption
Thermal only mode power consumption: 2.28W
The average power consumption of 24 hours: 2.51W
The max. power consumption: 6.24W (IR light on)
standby power consumption：0.39W
- Working Temperature/Humidity
Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
- Protection Level
IP67 Standard,IK10-rated housing
TVS 4000V lightning protection, surge protection, voltage transient protection
- Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22″ × 4.17″ × 4.14″)
- Adjustment Range
Bullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180°
Photovoltaic panel: Tilt: 10 ° or 30°
- Mount Pole Mount
- With Package Weight33.09kg(72.95lb)
- Storage Conditions
Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
- Startup and Operating Conditions
Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
- Battery
- Battery TypeLithium
- Battery Voltage10.8 V
- Battery Capacity360 Wh (90 Wh for each battery)
- Operating Temperature
Charging:-20 °C to 45 °C (-4 °F to 113 °F)
Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
- Battery LifeMore than 500 cycles
- Battery WeightApprox. 2.74 kg (6.0 lb.)
- Max. Output Voltage12.6 V
- Approval
- Protection
Camera: IP67 (IEC 60529-2013),IK10-rated housing
TVS 4000V lightning protection, surge protection, voltage transient protection
Wind resistance 12 level
