Qiymət sorğusu- Illuminator
- Light SupplementUp to 250m whitelight supplement
- Smart Function
- VCA4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
- System Function
- Click LinkageOne-Touch automatically calibration
- Tracking ModeManual/Auto
- Event TrackingIntrusion Detection, Line Crossing Detection
- Bullet Camera- Thermal Module
- Image SensorVanadium Oxide Uncooled Focal Plane Arrays
- Resolution256 x 192
- Pixel Pitch12 μm
- Spectral Range8 μm to14 μm
- NETD (Noise Equivalent Temperature Difference)< 25 mK (25°C, F1.0)
- Focal Length9.7 mm
- IFOV1.2 mrad
- Field of View19.5° × 15.4° (H × V)
- Min. Focusing Distance1.3 m
- ApertureF1.0
- Digital Zoomx2, x4, x8
- Bullet Camera- Optical Module
- Image Sensor1/1.8”CMOS
- Resolution2688 × 1520
- Focal Length8 mm
- Field of View39.4° × 21.96° (H × V)
- Min. IlluminationColor: 0.005 Lux @ (F1.5, AGC ON)
- ApertureF1.5
- Bullet Camera- General
- Main Stream
Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-stream
Thermal:
25 fps (704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
- Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
- Audio CompressionG.711ulaw/G.711alaw/G.726/MP2L2/AAC
- Alarm Input2-ch inputs (0-5 VDC)
- Alarm Output2-ch relay outputs, alarm response actions configurable
- Audio Input1-ch, Line input: 2 – 2.4 V [p-p], output impedance: 1 KΩ ± 10%
- Audio Output1-ch, Linear Level; Impedance: 600 Ω
- Communication Interface
1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface
1, BNC 1.0 V [p-p]/75 Ω video output
- Optical Speed Dome
- Image Sensor1/1.8” progressive scan CMOS
- Resolution2688 x 1520
- Min. IlluminationColor: 0.0003 Lux @(F1.3, AGC ON), 0 Lux with light on
- Focal Length6 – 240mm, 40 × optical zoom
- Field of View59°(H)*34.16°(V)-1.77°(H)*1.0°(V)
- Digital Zoom×2, ×4, ×8, x16
- Aperture RangeF1.3-F4.6
- Focus ModeAuto/Semi-auto/Manual
- WDR120 dB
- Optical DefogYes
- Image Enhancement3D DNR, EIS, HLC/BLC
- Pan Speedconfigurable from 1° to 160°/s
- Tilt Speedconfigurable from 1°/s to 90°/s
- Main Stream
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
60 Hz: 30 fps (704 × 480, 352 × 240, 176 × 120)
50 Hz: 25 fps (704 × 576, 352 × 288, 176 × 144)
- Video Compression
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
- Network StorageMicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- APIISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface,ONVIF (Profile S, Profile G)
- Simultaneous Live ViewUp to 20 channels
- User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
- SecurityUser authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
- ClientiVMS-4200, Hik-Connect
- Web Browser
Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0 +, Firefox 52.0 +
- General
- Power SupplyDC36V,AC24V,PoE++
- Power ConsumptionMax. 90W
- Working Temperature/Humidity
-40 °C to +70 °C (- 40 °F to 149 °F),
Humidity: 90% or less
- Protection LevelIP67 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
- Dimensions458.7mm x 266.6mm x 290mm
- 13.5kg
