- Camera
- Min. Illumination0.00 Lux@(F1.2, AGC ON)
- Image Sensor1/2.5″ CMOS Progressive Scan
- Day & NightOnly support night mode
- Angle AdjustmentCamera adjustment angle: -72°~90°
Middle bracket adjustment angle: -54°~54°
Bottom bracket adjustment angle: 360°
- Lens
- FocusManual focus
- Max. ApertureF2.1
- Focal Length & FOV6 mm: horizontal FOV 54°, vertical FOV 45°，diagonal FOV 74°
- Lens MountM12
- Illuminator
- Supplement Light TypeInfrared fill light (no red glow)
- IR Wavelength940nm
- IR RangeUp to 10m
- Video
- Max. Resolution1920 × 1620
- Main Stream50Hz:25fps（1920×1620，1920×1080, 1280 x 960, 1280×720）
60Hz:30fps（1920×1620，1920×1080, 1280 x 960, 1280×720） - Sub-Stream50Hz:25fps（704×576,640×480, 352×288,320×240）
60Hz:30fps（704×576,640×480, 352×288,320×240） - Third Stream50Hz:25fps（1920×1080, 1280 x 960, 1280×720）
60Hz:30fps（1920×1080, 1280 x 960, 1280×720） - Video Compression Main Stream: H.264 , H.265,H.264+, H.265+
Sub-Stream: H.264 , H.265 , MJPEG ,H.264+, H.265+
Third Stream: H.264 , H.265,H.264+, H.265+ - Video Bit RateMain Stream: 256kbps to 12288kbps
Sub-Stream: 256kbps to 4096kbps
Third Stream: 256kbps to 12288kbps - H.264 TypeBaseLine Profile / Main Profile / High Profile
- H.265 TypeMain Profile
- Bit Rate ControlConstant Bit Rate, Variable Bit Rate
- Audio
- Audio Compression G711U，G711A，G726，AAC，G722，PCM
- Audio Bit Rate64Kbps(G.711U)/64Kbps(G.711A)/16Kbps(G.726)/16Kbps(AAC)
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS,RTP, RTSP, NTP
- Simultaneous Live ViewUp to 8 channels
- APIHIK SDK, ONVIF (PROFILE S/G/T), ISAPI
- User ManagementUp to 16 users, 3 levels: Administrator, Operator and User
- Web BrowserIE8+, Chrome45+, Edge41+, Firefox45+
- Image
- Day/Night SwitchNight only
- Interface
- Ethernet Interface-RJ45: RJ45 + Molex Cable + I/O out
-M12: M12 Aviation Plug + Molex Cable + I/O out - AudioAudio Input: Built-in Mic
Audio Output: Built-in Speaker - TF Card StorageBuilt-in Micro SD Slot, storage capacity up to 1 TB
- Event
- Smart EventDistraction Prompt Detection, Fatigue Driving (Closing Eyes) Detection, Fatigue Driving (Yawn) Detection, IR Interrupting Sunglasses Detection, Smoking Detection, Phone call Detection, Seatbelt Unbuckled Detection, Driver Exception Detection,Driver Identification
- General
- Product Dimension108 mm × 64 mm × 97.8 mm (4.3″ × 2.5″ × 3.9″)
- Power ConsumptionDC: 0.88 A to 0.22 A,, max: 8W
POE: 0.25 A to 0.15 A, max: 9W - Camera MaterialMetal
- Product WeightApprox. 308 g (0.68 lbs.)
- Startup and Operating Conditions-30°C to 75°C (-22°F to 167°F), humidity 90% or less (non-condensing)
- Power SupplyDC 9-36 V
PoE (802.3af, 36 V to 57 V) - Cable Length50 cm
- Approval
- EMCCE: CE-EMC(EN 55024:2010 +A1:2015,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013）
- SafetyCE: CE-LVD(EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013)
- EnvironmentCE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863)
- Automotive and RailwayE-MARK (ECE R10)
