Qiymət sorğusu- Camera
- Min. Illumination0.00 Lux@(F1.2, AGC ON)
- Image Sensor1/4″ high-speed global shutter image sensor
- Day & NightOnly support night mode
- Angle AdjustmentLeft and Right: -43°~43°; Front and Back: -43°~67°; Horizontal: 0°~360°
- Lens
- Focal Length & FOV6 mm: horizontal FOV 54°, vertical FOV 31°，diagonal FOV 62°
- Lens MountM8
- Lens TypeFixed Lens
- Illuminator
- Supplement Light TypeInfrared fill light (no red glow)
- IR Wavelength940nm
- IR RangeUp to 10m
- Video
- Max. Resolution1280 × 720
- Main Stream50 Hz: 25 fps (1280 × 720)
60 Hz: 30 fps (1280 × 720) - Sub-Stream50 Hz: 25 fps (704×576, 640×480, 352×288, 320×240)
60 Hz: 30 fps (704×576, 640×480, 352×288, 320×240) - Third Stream50 Hz: 25 fps (1280 × 720)
60 Hz: 30 fps (1280 × 720) - Video Compression Main Stream: H.264 , H.265
Sub-Stream: H.264 , H.265 , MJPEG
Third Stream: H.264 , H.265 - Video Bit RateMain Stream: 256kbps to 8192kbps
Sub-Stream: 256kbps to 4096kbps
Third Stream: 256kbps to 4096kbps - H.264 TypeBaseLine Profile / Main Profile / High Profile
- H.265 TypeMain Profile
- Bit Rate ControlConstant Bit Rate, Variable Bit Rate
- Audio
- Audio Compression G711U，G711A，G726，AAC，G722，PCM
- Audio Bit Rate64Kbps(G.711U)/64Kbps(G.711A)/16Kbps(G.726)/16Kbps(AAC)
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS,RTP, RTSP, NTP
- Simultaneous Live ViewUp to 8 channels
- APIHIK SDK, ONVIF (PROFILE S/G/T), ISAPI
- User ManagementUp to 16 users, 3 levels: Administrator, Operator and User
- Web BrowserIE8+, Chrome45+, Edge41+, Firefox45+
- Image
- Day/Night SwitchNight only
- Interface
- Ethernet Interface-RJ45: RJ45+DC Cable
-M12: M12 Aviation Plug + Molex Cable - AudioAudio Input: Built-in Mic
Audio Output: Built-in Speaker - TF Card StorageBuilt-in Micro TF Slot, up to 256 GB(not for baseline. Note the Micro-TF card capacity when ordering)
- Event
- Smart EventDistraction Prompt Detection, Fatigue Driving (Closing Eyes), IR Interrupting Sunglasses Detection, Tampering Detection, Seatbelt Unbuckled Detection, Fatigue Driving (Yawn) Detection, Driver Exception Detection, Tampering Detection
- General
- Product Dimension91.5 mm × 91.5 mm × 107.9 mm (3.6″ × 3.6″ × 4.3″)
- Power ConsumptionDC: 0.19-0.78 A, 7 W MAX
- Camera MaterialMetal
- Product WeightApprox. 405 g (0.9 lbs.)
- Startup and Operating Conditions-30°C to 75°C (-22°F to 167°F), humidity 90% or less (non-condensing)
- Power SupplyDC 9-36 V
- Cable Length50 cm
- Approval
- EMCFCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B）
CE: CE-EMC(EN 55024:2010 +A1:2015,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013） - SafetyCE: CE-LVD(EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013)
- EnvironmentCE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863)
Reach SVHC: Regulation (EC) No 1907/2006 - Automotive and RailwayEN50155: EN 50155-2007,EN 50155-2017
EN45545: (EN 45545-2:2013+A1:2015);
E-MARK (ECE R10)
