Qiymət sorğusu- Product Model
- Product ModelDS-D4025CW-2FQ/A
- Product Type
- Product TypeSmall Pixel Pitch Indoor Full-color LED Display
- Cabinet
- Pixel ConfigurationSMD Triad LED (with glue)
- Pixel Pitch CategoryP2.5
- Pixel Pitch2.5 mm
- Pixel Density161185 dots/㎡
- Modules Component2 × 2
- Dimensions (W × H × D)600 mm × 337.5 mm × 29.5 mm (23.622″ × 13.287″ × 1.161″)
- Resolution240× 136
- Area0.2025 ㎡
- 3.4 kg (7.5 lb.)
- Cabinet MaterialAluminium die casting
- Maintenance MethodFront maintenance for all components
- Module
- Module Resolution120 × 68
- Display
- White Balance Brightness600cd/㎡
- Color Temperature3000-10000 K adjustable
- Viewing Angle160°(H)/160°(V)
- Contrast Ratio5000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 16 bit
- Power
- Max. Consumption≤ 370 W/㎡
- Average Consumption＜ 125 W/㎡
- Input Voltage100~240 VAC ± 10％
- Working Environment
- Working Temperature10 °C to 40 °C (14 °F to 104 °F)
- Working Humidity10% RH to60% RH (without condensation)
- Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
- Storage Humidity10% RH to85% RH (without condensation)
- General
- Product Dimension (W × H × D)Module: 4-in-1(443X360X52 mm)，20-in-1 (471X378X266 mm)
- Packing ListRegulatory Compliance and Safety Information × 1
Connecting screws, light beads, driver IC, iron sheets - Gross WeightModule: 4-in-1 (1.744 kg), 20-in-1 (8.72 kg)； Structure: 1-in-1 (2.8 kg)，5-in-1 (14 kg)
- Net WeightModule: 4-in-1 (1.224 kg), 20-in-1 (6.120 kg)
Structure: 1-in-1 (2.6 kg)，5-in-1 (13 kg)
- Bracket
- Modular Bracketstandard bracket:DP-D40XXCB22-1X1-Q0.3-NW-Q0.3-HC 1*1;DP-D40XXCB22-2X2-Q0.8-NW-Q0.8-HC 2*2,ultra-thin bracket:DP-D40XXCB22-1X1-Q0.2-NW-Q0.2-ZF
