Video konfrans üçün 2 meqapikselli PTZ kamera
Video konfrans üçün 2 meqapikselli PTZ kamera
Sorğu əsasında
Qiymət sorğusu- Product Type
- Product FormHighly-integrated
- Product CharacteristicsWired USB camera, wireless mirroring
- Communication Protocol
- Video Codec ProtocolMJPEG, H264
- Audio Codec ProtocolPCM 16 bit depth 48 kHz, AAC-LC 16 bit depth 48 kHz
- Other Communication ProtocolsUAC, UVC
- WI-FI StandardSupports 2.4 G and 5 G dual-band connection
- BluetoothSupports 5.0 (only for the remote control)
- Video Characteristic
- Video Input Resolution Capability
1 × HDMI IN, Max. 4K@30，
1 × Wireless Screen Mirroring, Max. 4K@30，
1 × Wireless Camera, Max. 1080P@30
- Video Output Resolution Capability
2 × HDMI OUT, Max. 4K@60,
1 × USB-C (UVC MJPEG), Max. 1080P@30
- Audio Characteristic
- Audio AlgorithmAudio Array Algorithm, Self-Adaption Audio Algorithm, Acoustic Echo Cancellation (AEC), Automatic Noise Suppression (ANS), Automatic Gain Control (AGC)
- AGC,Automatic Gain ControlSupported
- ANS, Automatic Noise SuppressionSupported
- AEC,Acoustic Echo CancelSupported
- Intelligent Noise ReductionSupported
- Camera
- Camera TypeBuilt-In
- Privacy MaskElectronic Privacy Cover
- Sensor1/2.8 inch, CMOS, Effective Pixel 8 Million
- Max Resolution4K@30 (3840 × 2160)
- Aperturef/2.5
- Focus Distance2.02 mm
- Backlight CompensationSupported
- Horizontal Field Angle109.9°
- Vertical Field Angle74.6°
- Field Angle118.8°
- Digital Magnification3x e-PTZ Electronic Head
- Automatic GainSupported
- Automatic ExposureSupported
- Preset PointSupported, 5 Presets; Supports Active Call, Update, Clear
- DNR2D & 3D
- White BalanceSupported, Automatic
- OtherSupports to adjust image parameters, brightness, contrast, saturation, sharpness, gain Supports a variety of view modes: Manual Mode, Smart View, Smart Tracking, Smart Gallery
- Loudspeaker
- Rated Power10 W
- Sensitivity78 dB ± 3 dB
- Size78 mm × 183.4 mm × 50 mm
- Electrical Impedance8 ± 1.2 Ω
- F0, Lowest Frequency Response Point240 Hz
- AI
- Speaker FollowSupported
- Intelligent FramingSupported
- Smart WindowSupported
- Electronic NameplateSupported
- USB
- Supported Operating SystemSupports Windows 7/10/11, and Mac OS
- Video SystemMJPEG (1080P@30 (1920×1080), 720P@30 (1280×720), 540P@30 (960×540), 360P@30 (640×360), 270P@30 (480×270)）
- USB AudioPCM 16 bit depth 48 kHz
- USB Video Communication ProtocolUAC, UVC
- Maintenance Function
- Maintenance ModeSupported. Managed by remote control.
- Maintenance FunctionSupports device configuration, and upgrade via multiple methods ( USB flash drive / cloud service online detection)
- Interface
- Video Input
1 × Built-in camera,
1 × HDMI IN
- Video Output2 × HDMI OUT
- Audio Input1 × 3.5 mm LINE IN
- Audio Output1 × 3.5 mm LINE OUT
- Network Interface1 × 10/100/1000 Mbps Self-Adaption Network
- USB
1 × USB3.0 Type-C,
2 × USB2.0 Type-A
- Power InterfaceDCJack, Φ2.0m
- Bluetooth
1 × 2.4G Remote Control Bluetooth,
1 × 2.4G Audio Bluetooth
- Wi-Fi1 × 2.4 G & 5 G
- Other Interface1 × MIC (POE power supply, reserved interface)
- Microphone
- Microphone typeBuilt-In
- Polar PatternOmni-Directional
- Pickup Range6 m
- Array Amount8
- Frequency Response Range100-20 kHz
- Sensitivity-38 db
- Signal-to-noise Ratio65 db
- Sampling Rate48 kHz
- General
- InstallationScrews + Buckles
- Weigh(Product)2.49 kg
- Weight(With Packing)≈ 5.360 kg
- Dimension (Product)616 × 145 × 104.23 mm
- Dimension(With Packaging)727 × 227 × 213 mm
- Power Waste24 W
- Input VoltageDC 12V
- Input Current2A
- Operating Temperature0 to 40 ℃
- Operating Humidity10%RH to 80%RH
- Tripod Connecting Hole1 × 1/4-20”Screw Hole
- Heat DissipationNo heat dissipation holes. Internal aluminum block for heat dissipation.
- Packing List1 × Remote Control, 2 × Battery, 1 × AC Powerline, 1 × Power Adapter ( with European/German plug adapter), 1 × Wall-Mounted Bracket, 1 × NFC Sticker, 1 × Expansion Screw, 1 × Quick Start Guide, 1 × Regulation Compliance and Safety Information, 1 × Thank You Card, 1 × 5 m USB 3.0 Cable (USB-C to USB-A)
- Certification Standard
- Certification CertificateCB/CE, Certification of Transport
