Qiymət sorğusu- Camera
- Image Sensor2 sensors, 1/1.8″ Progressive Scan CMOS
- Max. Resolution2688 × 1520
- Min. Illumination
Color: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR - Shutter Time1/25 s to 1/100000 s
- Lens
- Focal Length & FOV
Channel 1: 10 to 50 mm, horizontal FOV 32.2° to 7.8°, vertical FOV 18.1° to 4.4°, diagonal FOV 37.1° to 8.95°,
Channel 2: 8 mm, horizontal FOV 51.7°, vertical FOV 28.1°, diagonal FOV 60.2° - Focus 10-50mm:Auto; 8mm:fixed
- Iris Type10-50mm: Auto-iris; 8mm: fixed Iris
- Aperture10-50mm: F1.7; 8mm: F1.6
- Illuminator
- Built-in Supplement Light TypeIR light
- Supplement Light Number8
- Built-in Supplement Light RangeUp to 50 m
- IR Wavelength850 nm
- Radar
- Working Frequency79 to 81 GHz
- Modulation WaveformFMCW
- Detection DistanceUp to 50 m
- Speed Measuring Range
up to 120Km/h - Horizontal Detection Angle± 35°
- Vertical Detection Angle± 10°
- Coverage LanesUp to 3 lane(s)
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288) - Sub-Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288) - Third Stream
50 Hz: 25 fps (1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1280 × 720, 704 × 576, 352 × 288) - Video Compression Main stream: H.265/H.264/MJPEG,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Network
- ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,SFTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IGMP,QoS,IPv4/IPv6,UDP,SSL/TLS,ISUP,ARP
- APIISAPI,SDK,ISUP,ONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M)
- SecurityPassword protection,Complicated password,HTTPS encryption,Watermark,IP address filter,Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF,RTP/RTSP over HTTPS,Control timeout settings,Security audit log,TLS 1.2, 1.3,Host authentication (MAC address)
- Web BrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge
- Image
- Image SettingsSaturation,Brightness,Contrast,Sharpness,Gain,White balance,AGC,Adjustable by client software or web browser.
- Day/Night Switch
Schedule,Auto, Manual - Wide Dynamic Range (WDR)140 dB
- Image EnhancementBLC,3D DNR
- Interface
- Ethernet Interface1 RJ45 10M/100M/1000M self-adaptive Ethernet port(s)
- On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card card, up to 512GB
- Alarm 1 input(s),1 output(s)
- RS-4851 RS-485
- Road Traffic and Vehicle Detection
- CoverageUp to 3 lane(s)
- LPR Countries/RegionsMiddle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,
Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,
Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,
America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,
Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,
Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan - Accuracy (Under recommended installation and lighting conditions)Capture rate > 99%,
Vehicle moving direction recognition accuracy > 98.5%,
LPR accuracy > 98%,
Mistaken capture rate < 2% - No License Plate DetectionSupported
- Vehicle TypeCar,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
- Vehicle ColorRed, yellow, green, blue, pink, purple, cyan, brown, white, grey, black
Recognizable at daytime only. - Vehicle Manufacturer212 Manufacturers: AC SCHNITZER, AITO, APOLLO, Ashok Leyland, Audi, Aston Martin, Acura, Ankai, Ayvip, Alfa Romeo, Asiastar, Artega, ARCFOX, BAIC, Beiben Truck, BLUECAR, Bedford, Benz, BMW, BYD , Bufori, Buick, Bently, Brabus, Bugatti, Borgward, BONLUCK, Besturn, CADILLAC, Celis, Chevrolet, Citroen, Chery, Chrysler, Chang an, CNHTC, CHTC, Caterham, Conquest, C&C Trucks, CAMC, DAIHATSU, DMC, DS, Dacia, Dongnan, Dodge, Dongwo, Denza, Dongfeng, Daewoo, Dima, Denway, DORCEN, Eicher, Emgrand, Equss, EXEED, Ford, FORO, Fornasari, Ferrari, Fuqi, Fiat, Fisker, FQT Motor, Foton, FAW, FORLAND, FUSO, Force Motors, Fxauto, Faralli Mazzanti, GAC, Great Wall, GMC, Geely, Geometry, Hyundai, HENNESSEY, HINO, Honda, Haima, Haval, Hongqi, Isuzu, Infiniti, Iveco, IAT, IM, JAC, JBC, JEEP, Jaguar, JMC, JETOUR, JETTA, Joylong ,Koenigsegg, KIA , Kia-Borrego, King Long, Kama, KTM, LEVC, Lexus, Land Rover, Lincoln, Lamborghini, Lotus, Luxgen, Levdeo, Leopaard, Lynk & Co , Lada, Leading Ideal, LEAPMOTOR, LUMMA, Lorinser, Land Wind, MAN Trucks , MAXUS, MG, MINI, Mahindra, Mitsuoka, Maserati, Meiya , McLaren, Maybach, Mazda, Morgan, Mitsubishi, Mustang, Marvel R, Maple, MANSORY, Modern, NOMA, Nissan, Norinco, Neoplan, NIO, NETA, Opel, Ora, Oushang, Perodua, Porsche, Peugeot, PGO, Proton, Pagani, Polestar, POCCO, Qoros, RAM, Rolls-Royce, Renault, Roewe, Rohens, Ranz, Ruilan, Radar, Renault Samsung, SAAB, SCANIA , SCION, SMART, SML ISUZU, Suzuki, SAIC Datong, Subaru, Skoda, Startek, Soyat, Seat , SWM, Sany, SsangYong, Sojen, Silver, SATE, SOL, Skyworth, SGMW, SITECH DEV, TATA, Tankar, Tesla, Trumpchi, Techart, Toyota, UD, UAES, Volkswagen, VINFAST, Venucia, Volvo, VOYAH, VeiculoLongo, Weltmeister , XCMG, Xinyuan, XPENG, Yutong, YAMAHA, Zhonghua, Zotye, Zhinuo, ZEEKR, Zenvo
- Capture Speed Range5 to 120 km/h
- Face Detection
- Face CaptureChannel 1 supported
- General
- PowerDC 36 V ±20%, 1.2 A, max. 42 W, two-core terminal block
- MaterialAluminum alloy
- Dimension379.9 mm × 203.2 mm × 209.1 mm (15″ × 8″ × 8.2″) (L × W × H)
- Package Dimension516 mm × 378 mm × 328 mm (20.3″ × 14.9″ × 12.9″) (L × W × H)
- Weight Approx. 5 kg (11.02 lb.)
- With Package WeightApprox. 7.2 kg (15.87 lb.)
- Operating Condition-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)
- Storage Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
- General FunctionOne-key reset,Three streams,Privacy mask,Heartbeat,Password protection
- Language8 languages: English, Thai, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
- Approval
- RF
CE-RED: EN 301489-1 V2.2.3,EN 301489-3 V2.3.2,EN 302264 V2.1.1,EN IEC 62311:2020 - EMCCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
- SafetyCB: IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014+A11: 2017
- EnvironmentCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
- ProtectionIK10: IEC 62262:2002,IP66: IEC 60529-2013
