Qiymət sorğusu- Camera
- Image Sensor1/1.8″ progressive scan CMOS
- Max. Resolution2688 × 1520
- Min. IlluminationColor: 0.0005 Lux @ (F1.2, AGC ON),0 Lux with light
- Shutter Time1/50 s to 1/40,000 s
- Day & Night24/7 color imaging
- Lens
- Focal Length & FOV
2.8-12mm : Horizontal: 113.5° to 39°, Vertical: 58.4° to 22.7°, Diagonal: 141.3° to 44.3°
8-32mm : Horizontal: 41.9° to 15.1°°, Vertical: 22.9° to 8.64°, Diagonal: 48.8° to 17.3°
10-50mm: Horizontal: 32.2° to 7.8°°, Vertical: 18.1° to 4.4°, Diagonal: 37.1° to 8.95°
- Focus Auto
- Iris TypeDC-IRIS
- Aperture
2.8-12mm : F1.38,
8-32mm : F1.7,
10-50mm : F1.7
- Illuminator
- Built-in Supplement Light TypeWhite light
- Supplement Light Number3
- Built-in Supplement Light RangeUp to 50 m
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Sub-Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)
- Third Stream
50 Hz: 25 fps (1280 × 720, 704 × 576, 352 × 288)
60 Hz: 30 fps (1280 × 720, 704 × 576, 352 × 288)
- Video Compression
H.264 and H.265 encoding
Main stream: H.265/H.264/MJPEG
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline profile/Main profile/High profile
- H.265 TypeMain profile
- Audio
- Audio Compression G.711/G.722.1
- Audio Bit Rate8Kbps (G.711) /16Kbps (G.722.1)
- Network
- ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,SFTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,SSL/TLS,ISUP,ARP
- Simultaneous Live ViewUp to 6 channels
- APIISAPI,SDK,ISUP,ONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M)
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- SecurityPassword protection,Complicated password,HTTPS encryption,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Watermark,IP address filter,Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF,RTP/RTSP over HTTPS,Control timeout settings,Security audit log,TLS 1.2, 1.3,Host authentication (MAC address)
- Network StorageMicro SD/TF card (512 GB), local storage and CVR, NVR, ANR
- ClientHik-Central Master,Hik-Central Pro
- Web BrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge
- Image
- Image SettingsSaturation,Brightness,Contrast,Sharpness,Gain,White balance,Adjustable by client software or web browser.,AGC
- Day/Night SwitchAuto/Scheduled/Manaul
- Wide Dynamic Range (WDR)140 dB
- Image EnhancementBLC, 3D DNR
- Interface
- Ethernet Interface1 RJ45 10M/100M/1000M Ethernet interface
- On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card, up to 512GB
- AudioSupported
- Alarm 1 input interface, 1 output interface, 2 relays
- RS-4851 RS-485 interface
- Wiegand1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit)
- Event
- Basic EventHDD error,Network disconnected,IP address conflict
- Road Traffic and Vehicle Detection
- CoverageUp to 3 lane(s)
- Smart Function
Helmet Detection, Manned Non-Motor
Traffic flow detection：Average speed, traffic flow, queuing length, and traffic status
Incident detection: congestion, stopped vehicle, lane change, wrong-way driving, speeding, low-speed driving
- LPR Countries/Regions
Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,
Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,
Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,
America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,
Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,
Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- Accuracy (Under recommended installation and lighting conditions)
Capture rate > 99%,
Vehicle moving direction recognition accuracy > 98.5%,
LPR accuracy > 98%,
Mistaken capture rate < 2%
- No License Plate DetectionSupported
- Motorcycle LPRSupported
- Vehicle TypeCar,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
- Vehicle Color
Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black
Recognizable at daytime only
- Vehicle Manufacturer212 Manufacturers: AC SCHNITZER, AITO, APOLLO, Ashok Leyland, Audi, Aston Martin, Acura, Ankai, Ayvip, Alfa Romeo, Asiastar, Artega, ARCFOX, BAIC, Beiben Truck, BLUECAR, Bedford, Benz, BMW, BYD , Bufori, Buick, Bently, Brabus, Bugatti, Borgward, BONLUCK, Besturn, CADILLAC, Celis, Chevrolet, Citroen, Chery, Chrysler, Chang an, CNHTC, CHTC, Caterham, Conquest, C&C Trucks, CAMC, DAIHATSU, DMC, DS, Dacia, Dongnan, Dodge, Dongwo, Denza, Dongfeng, Daewoo, Dima, Denway, DORCEN, Eicher, Emgrand, Equss, EXEED, Ford, FORO, Fornasari, Ferrari, Fuqi, Fiat, Fisker, FQT Motor, Foton, FAW, FORLAND, FUSO, Force Motors, Fxauto, Faralli Mazzanti, GAC, Great Wall, GMC, Geely, Geometry, Hyundai, HENNESSEY, HINO, Honda, Haima, Haval, Hongqi, Isuzu, Infiniti, Iveco, IAT, IM, JAC, JBC, JEEP, Jaguar, JMC, JETOUR, JETTA, Joylong ,Koenigsegg, KIA , Kia-Borrego, King Long, Kama, KTM, LEVC, Lexus, Land Rover, Lincoln, Lamborghini, Lotus, Luxgen, Levdeo, Leopaard, Lynk & Co , Lada, Leading Ideal, LEAPMOTOR, LUMMA, Lorinser, Land Wind, MAN Trucks , MAXUS, MG, MINI, Mahindra, Mitsuoka, Maserati, Meiya , McLaren, Maybach, Mazda, Morgan, Mitsubishi, Mustang, Marvel R, Maple, MANSORY, Modern, NOMA, Nissan, Norinco, Neoplan, NIO, NETA, Opel, Ora, Oushang, Perodua, Porsche, Peugeot, PGO, Proton, Pagani, Polestar, POCCO, Qoros, RAM, Rolls-Royce, Renault, Roewe, Rohens, Ranz, Ruilan, Radar, Renault Samsung, SAAB, SCANIA , SCION, SMART, SML ISUZU, Suzuki, SAIC Datong, Subaru, Skoda, Startek, Soyat, Seat , SWM, Sany, SsangYong, Sojen, Silver, SATE, SOL, Skyworth, SGMW, SITECH DEV, TATA, Tankar, Tesla, Trumpchi, Techart, Toyota, UD, UAES, Volkswagen, VINFAST, Venucia, Volvo, VOYAH, VeiculoLongo, Weltmeister , XCMG, Xinyuan, XPENG, Yutong, YAMAHA, Zhonghua, Zotye, Zhinuo, ZEEKR, Zenvo
- Capture Speed Range5 to 120 km/h
- Blocklist and AllowlistMax. 50000 records
- General
- Operating SystemLinux
- Power
DC 12 V to 24 V, 1.25 A, max. 15 W, two-core terminal block,
PoE: 802.3at, Type 2, Class 4, max. 15 W
- MaterialAluminum alloy
- Dimension428.5 mm × 120 mm × 132.8 mm (16.9″ × 4.72″ × 5.2″) (L × W × H)
- Package Dimension595 mm × 259 mm × 193 mm (23.4″ × 10.2″ × 7.6″) (L × W × H)
- Weight Approx. 2.975 kg (6.56 lb.)
- With Package WeightApprox. 4.385 kg (9.67 lb.)
- Operating Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
- Storage Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
- General FunctionOne-key reset, three streams, heartbeat, password protection, watermark
- Language8 languages: English, Thai, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
- Approval
- EMCCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
- SafetyCB: IEC 62368-1: 2018+A11,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017
- EnvironmentCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
- ProtectionIK10: IEC 62262:2002,IP67: IEC 60529-2013
