- Chassis
- Chassis Height3 U
- Bus TypeGigabit network switching
- Main Control Board Slot1
- Installed Main Control Boards1
- Power Supply Slot2
- Installed Power Supplies1
- Service Board Slot6
- Installed Service Boards6
- Fans14 (2 fan boards, 7 fans per fan board)
- Network
- Network Interface2 × 10/100/1000 Mbps self-adaptive Ethernet interface (RJ-45)
- Video Wall
- Video Walls8
- Video Wall Scale≤ 32
- Open Windows512
- Input Source Copy CapabilitySupported
- Layers Per Port4 × 1080p or 2 × 4K
- Layers per Device128
- Scenes128
- Display Video Wall ImageSupported
- Scene Auto-Switch Delay3 s
- Live View ResolutionCIF(352 × 288)/QCIF(176 × 144)/HCIF(704 × 288)/DCIF(528 × 384)/FCIF(704 × 576)
- Background Image≤ 8, single background image resolution: 1280 × 720 to 7680 × 4320, background image format: JGP/JPEG.
- Subtitles≤ 8 subtitles on the video walls; ≤ 3 subtitles on a single video wall
- Input Image ClippingSupported, 200 pixels on the left, right, top and bottom edges.
- Local Signal Source Decoding Delay120 ms
- Window Division1, 2, 4, 6, 8, 9, 12, 16, 25
- General
- Working Humidity10% to 90%
- Net Weight≤ 9.4 kg (20.72 lb.)
- Gross Weight≤ 18 kg (39.68 lb.)
- Dimensions (W × H × D)442.4 mm × 128 mm × 341.6 mm (17.42 inch × 5.04 inch × 13.45 inch)
- Packing List1 × serial port cable, 1 × AC power cord, 1 × grounding cable, 1 × M4 screw, 1 × HDMI bracket, several HDMI snap fittings, 1 × regulatory compliance and safety information manual
- Video Input
- Video Input Interface TypeHDMI1.4
- Video Input Interfaces16
- Max. Video Input Resolution4K(Only odd-numbered ports)
- Video Input Resolution
1024 × 768@60 Hz, 1280 × 1024@60 Hz, 1366 × 768@60 Hz, 1440 × 900@60 Hz, 1680 × 1050@60 Hz, 1280 × 960@60 Hz, 1600 × 1200@60 Hz, 1280 × 720p@50 Hz, 1280 × 720p@60 Hz, 1920 × 1080p@50 Hz, 1920 × 1080p@60 Hz, 1920 × 1200@60 Hz, 3840 × 2160@30 Hz (only odd-numbered ports)
Supports custom resolution.
Width: 800 to 1920, pixel alignment: must be a multiple of 4
Height: 600 to 1200, pixel alignment: must be a multiple of 2
Resolution: 0.48 MP to 2.3 MP
- Video Encoding
- Video Encoding Channels16
- Video Encoding FormatH.265 (default), H.264
- Video Encoding Capability16 channels of 1080p 60 fps or 8 channels of 4K30
- Audio Encoding
- Audio Encoding FormatG722.1,G711_U,G711_A,AAC
- Video Output
- Max. Video Output Resolution4K
- Video Output ResolutionXGA_60 Hz(1024 × 768@60 Hz)/SXGA_60 Hz(1280 × 1024@60 Hz)/ 720P_60 Hz(1280 × 720@60 Hz)/UXGA_60 Hz(1600 × 1200@60 Hz)/ WSXGA_60 Hz(1680 × 1050@60 Hz)/WUXGA_60 Hz(1920 × 1200@60 Hz)/ 1080P_60 Hz(1920 × 1080@60 Hz)/4K_30 Hz(3840 × 2160@30 Hz)
- Loading Capacity for Video Output to LED
Single port load 2600000,
Width 288 – 3840,
Height 288 – 2160
- Video Output Interface TypeHDMI1.4
- Video Output Interfaces32
- Video Decoding
- Video Decoding FormatH.264, H.265, Smart264, Smart265, MJPEG
- Video Decoding Channels512
- Video Decoding Capability
H.264/H.265/Smart264/Smart265 format: 16 channels of 32 MP/24 MP, 32 channels of 16 MP, 48 channels of 12 MP, 64 channels of 8 MP, 80 channels of 6 MP, 128 channels of 4 MP, 256 channels of 1080p, or 512 channels of 720p/D1 or lower resolution (One group of 4 outputs shares decoding capability)
MJPEG format: 32 channels of 2 MP
- Audio Output
- Audio Output InterfaceHDMI embedded
- Audio Decoding
- Audio Decoding FormatG711-A, G711-U, G722.1, G726-16/U/A, MPG, AAC-LC
- Device Parameters
- Device Decoding Capability256 channels of 1080p 30 fps
- Device Splicing Capability32 channels
