24 yuvalı, ultra yüksək tutumlu, qənaətcil saxlama yeri
24 yuvalı, ultra yüksək tutumlu, qənaətcil saxlama yeri
Sorğu əsasında
Qiymət sorğusu- Performance Parameter
- Video performance450-ch (2Mbps)
- External Interface
- HDMIRear × 1
- General specification
- Chassis4U
- Dimension (W × H × D)447 × 175 × 787 mm (17.6 × 6.9 × 31.0 in)
- Weight (without HDDs)≤ 25kg
- ≤ 41kg
- Power ModuleRedundant 550W
- Rated power consumptionWorking: ≤ 522W
- Working humidity20% to 80%RH (non-condensing/frozen)
- Storage humidity5% to 90%RH (non-condensing/frozen)
- Network
- ProtocolRTSP, ONVIF, SDK, ISAPI
- External interface
- USB
USB 2.0: Front × 2
USB 3.0: Rear × 4
- Data network interface4 × 2.5G Ethernet interface(4 × GbE or 2 × GbE or 1 × GbE or 2 × 10GbE is extendable)
- COMRS-232 serial interface × 1
- Management network interface1, 1000M Ethernet interface
- Storage
- HDD slot24 (Pre-installed 20 HDDs. Fixed number of available slots.)
- Interface/capacitySATA/30 TB
- Hot-swappingSupported
- HDD supportEnterprise Hard Disk
- RAIDVRAID 2.0
- Hardware
- StructureController Structure
- Processor64-bit multi-core processor
- Cache16 GB
- Storage Management
- Disk managementDisk inspection, alarm and repair
- Recording Management
- Recording modeTiming recording, event recording
- Video protectionLock key video, ANR, video loss detection and alarm
- Searching modeSearch by time and event
- Downloading modedownload by time, download by file
- Device Maintenance
- Management modeWeb-based GUI, serial interface CLI, centralized management of multiple devices (HCP)
- Alarm modeSound, light, email, web page
- Log downloadingDownload on web page
- HDD
- HDD ModelHikvision, HK7230AH, 30TB;
