4 MP MD 2.0 Sabit Bullet Şəbəkə Kamerası
4 MP MD 2.0 Sabit Bullet Şəbəkə Kamerası
- Camera
- Image Sensor
1/2.9″ Progressive Scan CMOS
- Max. Resolution
1920 × 1080
- Min. Illumination
Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time
1/3 s to 1/100,000 s
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
- Lens
- Lens Type
Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94° - Lens Mount
M12
- Iris Type
Fixed
- Aperture
F2.2
- DORI
- DORI
2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m
- Illuminator
- Supplement Light Type
IR,White Light
- Supplement Light Range
IR: up to 20 m
White Light: up to 15 m - Smart Supplement Light
Yes
- IR Wavelength
850 nm
- Video
- Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720) - Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) - Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG - Video Bit Rate
32 Kbps to 8 Mbps
- H.264 Type
Baseline Profile,Main Profile,High Profile
- H.265 Type
Main Profile
- Bit Rate Control
CBR,VBR
- Region of Interest (ROI)
1 fixed region for main stream
- Audio
- Audio Type
Mono sound
- Audio Bit Rate
64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
- Environment Noise Filtering
Yes
- Audio Sampling Rate
8 kHz/16 kHz
- Audio Compression
G.711ulaw/AAC-LC
- Network
- API
Open Network Video Interface (Profile S, Profile T, Profile G (-F model supports)),ISAPI,SDK
- Security
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View
Up to 6 channels
- Protocols
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP,NTP, IGMP, IPv4, IPv6, UDP, QoS
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user - Client
iVMS-4200,Hik-Connect
- Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Wide Dynamic Range (WDR)
Digital WDR
- SNR
≥ 52 dB
- Day/Night Switch
Day,Night,Auto,Schedule
- Image Enhancement
BLC,HLC,3D DNR
- Image Settings
Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Privacy Mask
1 programmable polygon privacy mask
- Interface
- Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
-F model: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB - Built-in Microphone
Yes,1 built-in microphone
- Reset Key
-F model supports
- Event
- Basic Event
Motion detection (support alarm triggering by specified target type (human)), exception
- Linkage
Upload to memory card (-F model supports), send email, notify surveillance center, trigger recording (-F model supports), trigger capture
- General
- Power
12 VDC ± 25%, 0.45 A, max. 5.4 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 7 W - Material
Plastic
- Dimension
Ø121.5 mm × 97.6 mm (Ø4.78″ × 3.84″)
- Package Dimension
150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
-
Approx. 600 g (1.2 lb.)
- With Package Weight
Approx. 790 g (1.7 lb.)
- Storage Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
- Language
English, Ukrainian
- General Function
Heartbeat,anti-banding,mirror,password protection,password reset via email
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
KC: KN32: 2015, KN35: 2015 - Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 - Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
