Hikvision DS-2CD2747G2H-LIPTRZS
4 MP Smart Hybrid Light ilə ColorVu motorlu PTRZ varifokal dome şəbəkə kamerası
4 MP Smart Hybrid Light ilə ColorVu motorlu PTRZ varifokal dome şəbəkə kamerası
Sorğu əsasında
Qiymət sorğusu- Camera
- Image Sensor
1/2.7″ Progressive Scan CMOS
- Min. Illumination
Color: 0.007 Lux @ (F1.2, AGC ON), 0.01 Lux @ (F1.4, AGC ON), 0 Lux with IR
- Shutter Speed
1/3 s to 1/100,000 s
- Slow Shutter
Yes
- Wide Dynamic Range
120dB
- Day & Night
IR cut filter
- Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
- Lens
- Focus
Auto
- Lens Type
2.8 mm to 12 mm
- FOV
Horizontal FOV: 101° to 29°, vertical FOV: 54° to 16°, diagonal FOV: 121° to 34°
- Aperture
F1.4
- Lens Mount
Φ14
- Aperture Type
Fixed
- Illuminator
- IR Range
Up to 30 m
- Wavelength
850 nm
- Video
- Max. Resolution
2688 × 1520
- Main Stream
50Hz: 25fps (2688 × 1520, 1920 × 1080, 1280 × 720),60Hz: 30fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Video Compression
Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG
- Video Bit Rate
32 Kbps to 16 Mbps
- H.264 Type
Main Profile/High Profile
- H.265 Type
Main Profile
- Scalable Video Coding (SVC)
H.265 encoding and H.264 encoding support
- Region of Interest (ROI)
Support 1 fixed region for main stream and sub stream separately
- Audio
- Environment Noise Filtering
Yes
- Audio Sampling Rate
8kHz/16kHz
- Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
- Network
- Simultaneous Live View
Up to 6 channels
- API
ONVIF (PROFILE S, PROFILE G), ISAPI
- Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- User/Host
Up to 32 users,3 levels: Administrator, Operator and User
- Network Storage
Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
- Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
- Web Browser
Plug-in required live view:,IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+,Plug-in free live view:,Chrome 45.0+, Firefox 52.0+
- Alarm Trigger
Tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
- Image
- Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In(-S)
- DNR
3D DNR
- Image Enhancement
BLC/3D DNR
- Image Settings
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Interface
- Audio
1 audio input (line in), 1 audio output (line out), mono sound
- Alarm
1 alarm input, 1 alarm output
- On-board Storage
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
- Hardware Reset
Yes
- Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
- Event
- Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exit detection, false alarm filter by target classification
- General
- Firmware Version
V5.5.63
- General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering
- Startup and Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
- Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug,PoE (802.3af, class 3)
- Power Consumption and Current
12 VDC, 0.9 A, max. 11 W,PoE: (802.3af, 36 VDC to 57 VDC), 0.4 A to 0.2 A, max. 12.9 W
- Camera Dimension
Camera: Φ 153.3 × 111.6 mm (Φ 6″ × 4.4″)
- Camera Weight
Camera: 890 g (2 lb.),With package: 1300 g (2.9 lb.)
- Approval
- Protection
IK10, IP67 (If the camera is installed outdoor, the bracket DS-1253ZJ-L should be used together with other pendant mounting bracket or wall mounting bracket to reduce IR reflective in the rainy day)
