- System
- MotorBrushless Motor
- MCBF≥ 5 million times
- BrakeNot support
- dToF sensor2 arrays of sensors
- Video
- LensDual lens
- Video compression standardH.264
- Resolution2 MP
- WDRSupport
- Video standardPAL by default, support NTSC
- HOV
Horizontal: 75°
Vertical: 139°
- Audio
- Audio compression standardG.711U
- Audio compression bitrate64 Kbps
- Audio outputSupport
- Volume adjustmentSupport
- Power output5.5W
- Network
- Wired networkSupport,10M/100M
- Wi-FiSupport
- Interface
- Network interface1
- Lock control0
- Exit button2
- Alarm output4
- RS-4852
- RS-2322
- Wiegand2
- USB2
- Fire alarm input1
- Case input2
- Hardware
- Access controllerSupplied
- SupercapacitorSupplied
- Network switchNot supplied
- Capacity
- Face capacity100,000
- Card capacity200,000
- Event capacity100,000
- Person Capacity100,000
- Authentication
- Face recognition distance0 m to 2 m
- Face recognition accuracy rate＞99%
- Face recognition duration＜200 ms
- CardEM card or M1 card or Desfire card formats (actual corresponding card type refer to product model names).
- Card reading frequency13.56 MHz or 125 KHz
- Card reading distance3cm
- Card reading duration＜1s
- Function
- Configuration via PC WebSupport
- Configuration via mobile WebSupport
- Hik-ConnectSupport
- Multi-factor authenticationSupport
- Face anti-spoofingSupport
- Built-in face recognitionSupport
- Communication protocolTCP/IP,ISAPI,RTSP
- KeyfobSupport, 433 MHz or 868 MHz, within 50 m
- General
- Lane width550 mm to 1400 mm (21.65″ to 55.12″)
- Pedestal materialSUS304 stainless steel 1mm
- IndicatorLane status indicator, authentication indicator andbarrier light
- Power consumption
Standby: 55 W
Working: 100 W
Peak: 200 W
- Working temperature -15 °C to 65 °C (5 °F to 149 °F)
- Working humidity10% to 95% (No condensing)
- Protective levelIPX4
- Dimensions
Without package: 1054 mm × 200 mm × 200 mm (41.48″ × 7.87″ × 7.87″)
With package: 1160 mm × 290 mm × 300 mm (45.66 × 1.77″ × 2.59″)”
Net: 15.5 kg (34.17 lb)
Gross: 18 kg (39.68 lb)
- Approval CE/CB/RoHS/REACH/WEEE
- Power supply methodPower supply: 100 to 240 VAC~, 50/60 Hz, 0.8A
- LanguageEnglish, Japanese, Thai, Indonesian, Russian, Spain (European), Spain (Latin America), Portugal (Brazil), Arabic, Kazakh, Uzbek, Ukraine
- Interconnecting cable length5.5m
- Door open duration5 to 60 sec
- Configuration
- Module selectionNO
