- System
- MotorBrushless motor
- MCBF≥ 6 Millions
- IR light detectorsNot Support
- BrakeSupport
- Interface
- Exit button1
- USB1
- Fire alarm input1
- Hardware
- BuzzerSupport
- Access controllerOptional
- SupercapacitorSupport
- Network switchNot supplied
- Card receiverOptional
- Function
- AP modeNot Support
- KeyfobSupplied, 433 MHz/868 MHz, within 30 m
- General
- Throughput30 to 60 persons per minute
The actual throughput is affected by the person passing rate and passing method - Lane widthFor pairs mode： 550~1400mm（Gap 50mm，Door wing height 950mm）For full-height door wing 550~900mm (Gap 50mm，Door wing height 1800mm) For single mode： 650~900mm（Gap 25mm，Door wing height 950mm)
- Distance between barrier and ground950mm - 1800mm
- Barrier materialAcrylic glass or Tempered glass
- Pedestal materialSUS304 stainless steel with the thickness of 2 mm (0.08")
- IndicatorSupport
- Power24 VDC
- Power consumption36W (stand by)
- Working temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working humidity10% to 95% (No Condensing)
- Dimensions180mm x 180mm x 973mm (7.09' x 7.09' x 38.31')
- (Net) Left: 30kg (66.14 lbs)
(Rough) Left: 35 kg (77.16 lbs) - ApprovalCE/CB/CE-LVD/RoHS/REACH/WEEE
- Power supply for face recognition moduleSupplied
- Configuration
- Lane widthdouble:650,750,900,1100,1200;single:650,700,750,800,850,900;
- Pedestal length180 mm
- Module selectionYES
- Pedestal width180 mm
- Wall distance20 mm
- BaseNO
- Barrier materialAcrylic glass
- Application environmentIndoor
- Authentication modeCard;Face;QR code
- Card typeDesfire;M1;EM
- Recommended width650 mm
- Base modelNO
- Authentication exclusionaryCard;Face;QR code
- Product typeSwing barrier
- Remote controller type433Mhz;868Mhz
- Movement Protrusion Width0 mm
- Convert FaceNO
- Door HeightDefault(0.95m);1.8m;
- Door wing gapDefault:50mm
