Qiymət sorğusu- System
- Motorbrushless motor
- MCBF≥ 3 million times
- IR light detectors6 pairs
- Interface
- Network interface0
- Lock control0
- Exit buttonMain: 1
Sub: 1 - Alarm output0
- RS-485Main: 0
Sub: 0 - RS-232Main: 0
Sub: 0 - Fire alarm input1
- Hardware
- Access controllerNot supplied
- Capacity
- Card capacityNA
- Event capacityNA
- General
- Throughput20 to 60 persons per minute
The actual throughput is affected by the person passing rate and passing method. - Lane width550 mm (21.65″)
- Barrier material12 mm acrylic glass
- Pedestal materialSUS304 stainless steel
- Power consumptionStandby: 30 W
Working: 70 W
Peak: 120 W - Working temperature -20 °C to 70 °C (-4 °F to 158 °F)
- Working humidity10% to 95% (No condensing)
- DimensionsWithout package: 1206 mm × 315.2 mm × 990 mm (47.48″ × 12.41″ × 38.98″)
With package: 1340 mm × 415 mm × 1090 mm (52.76″ × 16.34″ × 161.02″) - InstallationUse four M12 expansion screws
- Net:
Left: 45.59 kg (99.21 lb)
Middle: 55.79 kg (123.00 lb)
Right: 48.33 kg(106.55 lb)
Gross:
Left: 82.72 kg (182.37 lb)
Middle: 93.10 kg (205.25 lb)
Right: 85.64 kg (188.80 lb) - Power supply method100 to 240 VAC, 50 to 60 Hz
- Configuration
- Module selectionNO
