- Door station/System parameters
- Operation systemEmbedded Linux operation system
- RAM256 MB
- Door station/Video parameters
- Camera2MP HD camera
- Night visionLow illumination IR supplement mode:3 m
- Backlight compensationSupport
- Digital noise reductionSupport
- WDRSupport
- Field of viewHorizontal: 146°, Vertical: 82°
- Video Compression StandardH.264; H.265; MJPEG
- Motion detectionSupport
- Door station/Audio parameters
- Audio inputBuilt-in omnidirectional microphone
- Audio outputBuilt-in loudspeaker
- Audio qualityNoise suppression and echo cancellation
- Audio compression standardG711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
- Audio compression Rate64 Kbps
- Door station/Network parameters
- Network protocolTCP/IP, RTSP, IPV6,ONVIF
- Wired network10/100 Mbps Ethernet
- Door station/Device interfaces
- Network interface1 RJ45
- RS-485 1 (1 for Hikvision’s sub module communication)
- Alarm input 4 (2 exit butttons and 2 door contacts by default)
- Debugging port1
- Lock control2 (2 relay, max to 30 V, 2 A)
- TAMPER switch1
- Power interface12 VDC power output (max to 12 V, 500 mA)
- Door station/General
- Power consumption≤ 5 W
- Working temperature -40° C to 60° C (-40° F to 140° F)
- Working humidity10% to 95%
- DimensionDevice: 98 mm × 100 mm × 42 mm (3.86″ × 3.94″ × 1.65″)
Cover: 117 × 107 × 4 mm (4.61″ × 4.21″ ×0.16″)
Installation Frame: 117 × 107 × 32.7mm (4.61″ × 4.21″ ×1.29″) - InstallationSurface mounting
- Protection level IP65
- Indicator0
- Power supplyIEEE802.3af, standard PoE
12 VDC
- Indoor station/System parameters
- Operation systemEmbedded Linux operation system
- ROM32 MB
- RAM128 MB
- ProcessorEmbedded high performance processor
- Indoor station/Display parameters
- Screen size7-inch colorful TFT screen
- TypeColorful TFT screen
- Operatiing methodCapacitive touch screen
- Resolution1024 × 600
- Indoor station/Video parameter
- Lens/
- Resolution/
- Wide dynamic range (WDR)/
- FOV/
- Video compression standard/
- Indoor station/Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio compression standardG.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
- Audio output1 built-in loudspeaker
- Audio compression Rate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Indoor station/Capacity parameters
- Notice capacity200
- Linked network camera capacity16
- Linked indoor extensions capacity16
- Linked doorphone capacity17
- Indoor station/Network parameters
- Network protocolTCP/IP, RTSP, SIP, IPv6, ONVIF
- Wi-FiWiFi 802.11b/g/n
- BluetoothReserved
- 3G/4G/
- Indoor station/Device interfaces
- Alarm input8
- Network interface1 RJ-45 10/100Mbps self-adaptive
- TAMPER/
- RS-4851
- USB/
- TF cardSupport TF card, up to 128 G
- Alarm output/
- Power supply outputMax. 12VDC 0.2 A (Only when powered by PoE)
- Debugging port1
- Relay2 relays, Max. 30VDC 0.3A
- Indoor station/General
- Button/
- Power supplyIEEE802.3af, Standard PoE,12 VDC
- Power consumption≤ 12 W
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)200 mm × 140 mm × 23.3 mm (7.87″ × 5.51″ × 0.92″)
- InstallationSurface mounting
- Application environmentIndoor
- Protective level/
- Without package: 339.1 g (0.75 lb),With package: 562.4g (1.24 lb)
- LanguageEnglish, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
