Operation system | Android 7.1 |
ROM | 4 GB |
RAM | 2 GB |
Processor | Embeded high performance processor |
Screen size | 10.1-inch |
Operation method | Capacitive touch screen |
Type | Colorful IPS |
Resolution | 1280 × 800 |
Brightness | 410 cd/m2 |
Lens | 2 × 2 MP HD camera |
Resolution | Main stream:1920 × 1080p and 1280 × 720p;Sub stream: 1280 × 720p and 640 × 480p |
FOV | Horizontal: 88°, Vertical: 44° |
Wide dynamic range (WDR) | Digital WDR/120 dB |
Supplement light | IR light, up to 3 m |
Video compression standard | H.264 |
Audio input | 2 built-in omnidirectional microphone |
Audio compression standard | G.711 U, G.711 A |
Audio output | 1 built-in loudspeaker |
Audio compression bitrate | 64 Kbps |
Audio quality | Noise suppression and echo cancellation |
Volume adjustment | Adjustable |
User capacity | 20000 |
Face capacity | 10000 |
Fingerprint capacity | / |
Card capacity | 100000 |
Message capacity | / |
Linked indoor station capacity | 500 |
Sub door station capacity | 16 |
Network protocol | TCP/IP, RTSP |
Wi-Fi | / |
Bluetooth | / |
3G/4G | / |
Card reading frequency | 13.56 MHz |
Alarm input | 4 (2 exit butttons and 2 door contacts by default) |
Network interface | 2 RJ-45 10/100/1000 Mbps self-adaptive (1 reserved) |
TAMPER | 1 |
Exit button | 2 (1 for lock control and 1 for secure door control unit) |
RS-485 | 2 RS-485 (Half duplex, HIKVISION) |
USB | 2 for internal use only |
Wiegand | / |
TF card | 1 (reserved) |
Alarm output | 2 (reserved) |
Lock control | 2 relays, Max. 30 VDC, 2 A, lock 2 needs secure module |
Door contact input | 1 |
Button | / |
Installation | Surface mounting and flush mounting |
Indicator | / |
Weight | Net weight: 1.270kg;Gross weight: 3.328kg |
Protective level | IP65 and IK07 |
Working temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
Working humidity | 10% to 90% (no-condensing) |
Dimension (W × H × D) | 271 mm × 159.2 mm × 26.5 mm (10.7″ × 6.3″ ×1″) |
Battery | / |
Power supply | 12 VDC, 2 A |
Application environment | Outdoor |
Power consumption | ≤ 18 W |
Language | English,French,Portuguese,BrazilianPortuguese,Spanish,Russian,German,Italian,Polish,Turkish,Vietnamese,Arabic,Czech,Hungarian,Dutch,Romanian,Bulgarian,Ukrainian,Croatian,Serbian,Greek,Lithuanian,Estonia,Latvian,Norwegian,Danish,Slovakia,Hebrew,Swedish,Finnish,TraChinese,Mongolian,HongKongTraChinese |
