Hikvision DS-KH7000EY-E2 — аудио 2-wire HD внутренняя панель
Hikvision DS-KH7000EY-E2 — аудио 2-wire HD внутренняя панель
По запросу
Запрос ценыProcessor | Embedded Processor |
ROM | 4 GB |
RAM | 256 MB |
Operation system | Embedded Linux operation system |
Screen size | NA |
Resolution | NA |
Type | NA |
Operation method | NA |
Supplement light | Supplement lightLow illumination, IR supplement lights |
Resolution | 2MP |
Lens | 1 |
Wide dynamic range (WDR) | Support |
FOV | Horizontal: 133°, Vertical: 82° |
Video compression standard | H.264 |
Audio input | Built-in omnidirectional microphone |
Audio output | Built-in loudspeaker |
Volume adjustment | Adjustable |
Audio compression standard | G.711 U, G.711 A |
Audio compression bitrate | 64 Kps |
Audio quality | Noise suppression and echo cancellation |
Linked indoor station capacity | Max.99 |
Sub door station capacity | 16 |
Wireless network | 10/100 Mbps self-adaptive through 2-wire interface |
Wi-Fi | Only AP mode for configuration |
RS-485 | 2 (RS485 out for Hikvision’s sub module communication, RS485 for reservation) |
Lock control | 2 (1 relay, max to 30 VDC, 2 A；1 DC pulse，20V 4A impulsive，300 mA holding current，30 ohm max ) |
Exit button | 1 |
Door contact input | 1 |
Alarm input | 2（supports Exit button or Door contact input） |
Power supply input | 12VDC input |
TAMPER | 1 |
Debugging port | 1 |
Two-Wire | 1 |
DIP Switch | 6 decimal DIP switch |
Button | 0-2（Flexible adjustment） |
Indicator | 4 LED lights(Opening door、Calling、Intercom、In use） |
Power supply | 48V，Powered by distributorDS-KAD7060EY or 12VDC |
Power consumption | ≤ 6 W |
Working temperature | -40° C to 60° C (-22° F to 140° F) |
Working humidity | 10% to 90% |
Application environment | Outdoor |
Dimension (W × H × D) | 99.5 mm × 98.5 mm × 35 mm (3.92″ × 3.88″ × 1.37″) |
Installation | Surface mounting & flush mounting |
Protective level | IP65 IK08 |
Language | English, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch , Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese |
Power interface | 48VDC |
Two-wire interface | 6(«IN»»OUT» for casacading, CH1-CH4 for Door station and Indoor station) |
Power supply | 48VDC |
Power consumption | CH1＜30W，CH2＜30W，CH3＜30W，CH4＜30W；MAX Total 30W |
Working temperature | -10 °C to 5 °C (14 °F to 131 °F) |
Working humidity | 10% to 90% (no-condensing) |
Dimension (W × H × D) | 143.7 mm × 92.4 mm × 65.9 mm (5.66″ × 3.64″ × 2.59″) |
Installation | DIN rail installation |
Indicators | 6 Signal indicators;;1 Power indicator |
