Product Dimensions (W × H × D) |
80 mm × 41.94 mm × 136 mm (3.15» × 1.65» × 5.35») |
|
Package Dimensions (W × H × D) |
256 mm × 231 mm × 86 mm (10.07″ × 9.09″ × 3.38″) |
|
Net Weight |
0.12 kg (0.26 lb) per device |
|
Gross Weight |
0.7 kg (1.54 lb) |
|
Packing List |
Wireless Bridge × 2,Power Adapter (12 VDC, 1 A) × 2,10/100 Mbps PoE Injector × 2,Binding Tape × 4,Quick Start Guide ×1,Regulatory Compliance and SafetyInformation × 1 |
|
Packing Method |
Packing in pairs |
|
Working Temperature |
-30 °C to 70 °C (-22 °F to 158 °F) |
|
Working Humidity |
5% to 95% (no condensation) |
|
Storage Temperature |
-40 °C to 80 °C (-40 °F to 176 °F) |
|
Storage Humidity |
5% to 95% (no condensation) |
|
Installation Mode |
Pole Mounting |
|
Ingress Protection |
IP41 |
|
Power Consumption |
1 W for typical (1-ch 2MP IPC), Max. 2 W |
|
Max. Transmission Rate of Air Interface |
≤ 72 Mbps |
|
Wireless Standard |
IEEE 802.11b/g/n |
|
Working Frequency Band |
2400 MHz ~ 2483.5 MHz |
|
Antenna Gain |
7 dBi |
|
Antenna Angle |
(H) Beamwidth [3 dB] 50° (V) Beamwidth [3 dB] 50° |
|
Transmitting Power |
23±1.5 dBm (Note: Transmitting power may vary with local regulations.) |
|
Receiving Sensitivity |
-86±1.5dBm@HT20 MCS0；-68±1.5dBm@HT20 MCS7 |
|
Throughput Rate |
Point to point: Support up to 6-ch IPC (2MP) in Max. 0.2 KM distance and Max. 30 Mbps bandwidth |
|
Network Interface |
1 × 10/100 Mbps RJ45 ports |
|
LED Indicator |
Power indicator,LAN indicator,Signal intensity indicator |
|
Reset |
Hardware resetting button |
|
Power Supply |
12-24 VDC Passive PoE |
|
Channel Width |
10/20 MHz |
|
Channel Selection |
Auto/manual selection |
|
Network Protocol |
NTP (network time synchronization),SADP (auto search for IP address),SSH (debugging) |
|
Security Mode |
WPA2-PSK |
|
Security Mechanism |
Wireless network name hidden |
|
Management Method |
Web,iVMS-4200 |
|
Upgrade |
Web,iVMS-4200 |
|
System Log |
Syslog |
|
Application Function |
Support adaptive frequency hopping. Support fault self-healed. |
|
EMC |
CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020) |
|
Safety |
CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition)), CE-LVD (EN 62368-1: 2014+A11: 2017) |
|
Chemistry |
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006) |
|
Radio |
EN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17 |
