Hikvision DS-TCL400-E

Sensor Type

1/1.8″ Progressive Scan CMOS

Min. Illumination

Color: 0.04 Lux (F1.6, AGC ON);B/W: 0.02 Lux (F1.6, AGC ON)

Max. Resolution

2688 × 1520

Shutter

1/30 s to 1/100,000 s

Day/Night Switch

Supported

IR Cut Filter

IR cut filter ;Blue glass module to reduce ghost phenomenon

Lens Type

2.8mm

Aperture

2.8mm：F1.6

Focal Length & FoV

2.8 mm, horizontal FoV: 103.9°, vertical FoV: 56.2°, diagonal FoV: 123.5°

Focus

Fixed

Supplement Light Type

Warm White Light

Supplement Light Range

10m

WDR

140db

Defog

supported

Main Stream

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

Image Settings

Saturation, brightness, contrast, white balance, and gain are adjustable by client;software or web browser.

Day/Night Switch

Auto/Scheduled/Manual

WDR Switch

On, Time, Brightness

Frame Rate

25fps

ROI

8 regions respectively for main stream and sub-stream, 6 levels for each region.

Video Compression

H.265/H264/MJPEG

H.264 Type

Low profile ;Medium profile;High Profile

Video Bit Rate

32 Kbps to 16 Mbps

Bit Rate Type

Constant, Variable

Scalable Video Coding (SVC)

MJPEG , H.265 and H.264 encoding

Trigger Type

Parking Detection

Picture Type

Scene Picture、Composition、Close-up Picture

Scene Mode

Parallel Parking、Reverse Parking

Capture Type

Checkpoint Capture

Image Format

JPEG

Capture Resolution

2688*1520 (default)1920*1080,1280*720, 704*576,352*288

Smart Recognition

License plate recognition, vehicle entering/exiting parking space status, parking spacestatus detection, parking over spaces detection, parking over line detection

Capture Picture Overlay

Location, shooting time, license plate number, shooting number, vehicle color Vehicle type, etc

Network Storage

NAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported

Protocol

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNSDDNS,RT,RTSP,RTCP,NTP,SNMP，OTAP

API

ONVIF(PROFILE S,PROFILE G), ISAPI, SDK

Client

HikCentral,SDKdemo,TPE400

Web Browser

Plug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+

Security

One-key restoration, password protection, watermark

Video Compression

H.264/H.265/MJPEG

Video Bit Rate

32 Kbps to 16 Mbps

Protocol

TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP

General

Heartbeat, password protection, and NTP time sync.

RS-485

1-ch RS-485 serial port

Alarm Input

Not Supported

Alarm Output

Not Supported

RS-232

1-ch RS-232 serial port

Network Interface

2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface

Memory Card Slot

Not Supported

Power Supply

12 to 24 VDC;Hik-PoE（with DS-TPM400）;12 to 24 VDC, wide voltage

Protection

IP67

Weight

2 kg (4.4 lb.)

Working Temperature and Humidity

-20 °C to 70 °C (-4 °F to 158 °F);5% to 95% @ 40°C (non-condensing)

Working Environment

90% or less (non-condensing)

Dimensions

114.3 × 114.3 × 917.5 mm (4.5 × 4.5 × 36.1 inch)

Power Consumption

Max. 10 W

Weight (with Package)

3 kg (6.6 lb.)

Dimensions (with Package)

150 × 150 × 1000 mm (5.9 × 5.9 × 39.3 inch)

Storage Temperature and Humidity

Temperature: -20 °C to 70 °C (- 4°F to 158 °F);Humidity: 95% (non-condensing)

Startup and Operating Conditions

Temperature: -20 °C to 70 °C (- 4°F to 158 °F);Humidity: 95% (non-condensing)

Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

ANPR Supported Country/Region

Middle East:;The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain;Africa:;Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria;Asia-Pacific:;Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, HongKongChina, Macao, TaiwanChina, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka;America:;Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala;Europe:;Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina;Speaking Regions:;Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
