По запросу
Запрос цены- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP10
- Pixel Pitch10 mm
- Modules Component2 × 4
- Dimensions (W × H × D)1280 mm × 960 mm × 106 mm
- Resolution128 × 96
- Area1.2288 m²
- 26 kg (57.3 lb.)
- Pixel Density10000 dots/m²
- Lamp Board HousingWith housing
- Cabinet MaterialAluminum Profile
- Maintenance MethodRear maintenance
- Protection LevelIP66
- Display
- White Balance Brightness6000 cd/㎡
- Color Temperature9300K adjustable
- Viewing AngleHorizontal 160°, vertical 130°
- Contrast Ratio≥ 8000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency50/60 Hz
- Refresh Rate7680 Hz
- Grey Level14~16 bit adjustable
- Key Material
- Lamp Encapsulation2727 (Copper)
- Control SystemHikvision
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≤580 W/m² （6000nits）
- Average Consumption≤193 W/m² (6000nits)
- Working Environment
- Working Temperature-30 ℃ to 50 ℃ (-22℉ to 122 ℉)
- Working Humidity10%~95%RH (No condensation)
- Storage Humidity10%~95%RH (No condensation)
- Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- General
- Gross Weight30.5kg /1 in 1
- Package Dimension (W × H × D)1410 (W) mm × 210 (H) mm × 1057 (D) mm
- LifespanLamp 100,000 hours
