Запрос цены- Product Model
- Product ModelDS-D4012CS-1F
- Product Type
- Product TypeLED Display Structure
- Cabinet
- Pixel ConfigurationSMD Triad LED
- Modules Component2 × 3
- Dimensions (W × H × D)640 (W) mm × 480 (H) mm ×36 (D) mm (25.197» × 1.898» × 1.42»)
- Area0.3072 ㎡
- 6 kg (13.23 lb.)
- Cabinet MaterialDie cast aluminum
- Maintenance MethodComplete front maintenance
- Module
- Dimension (W × H × D)320 mm × 160 mm
- Module Resolution256 × 128
- Display
- White Balance Brightness600 cd/㎡
- Color Temperature3000-10000 K adjustable
- Viewing Angle160°(H)/160°(V)
- Contrast Ratio5000:1
- Color Uniformity≤ ± 0.003Cx，Cy
- Brightness Uniformity≥ 97％
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh Rate3840 Hz
- Grey Level Up to 16 bit
- Power
- Max. Consumption450W/㎡
- Average Consumption150W/㎡
- Input Voltage100~240 VAC ± 10％
- Working Environment
- Working Temperature-10 ℃ to 40 ℃ (14 ℉ to 104 ℉)
- Working Humidity 10% to 60% RH (without condensation)
- Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
- Storage Humidity10% to 85% RH (without condensation)
- General
- Package Dimension (W × H × D)760 (W) mm × 318 (H) mm × 587 (D) mm (29.92 » × 12.52 » × 23.11 »)
- Packing ListRegulatory Compliance and Safety Information × 1
Several Joint pieces,Fixing screws and Signal cables
Several LED lamp beads and IC components - Gross Weight4.7 kg (10.3 lb.)
- Net Weight3.7 kg (8.15 lb.)
- Bracket
- Modular BracketDS-DL116448W 1*1;DS-DL126448W 1*2;DS-DL226448W 2*2
