Светодиодный блок высокой яркости P1.2 COB 2-го поколения
Светодиодный блок высокой яркости P1.2 COB 2-го поколения
По запросу
Запрос цены|
Product Model |
DS-D4009BW-2FC |
|
Product Type |
Fine Pixel Pitch Indoor Full-color LED Display |
|
Pixel Pitch |
0.9375 mm (0.037″) |
|
Pixel Pitch Category |
P0.9 |
|
Pixel Configuration |
Flip-chip COB |
|
Pixel Density |
1137777 dots/㎡ |
|
Modules Component |
2 × 2 |
|
Dimensions (W × H × D) |
600 mm × 337.5 mm × 29.3 mm (23.622″ × 13.287″ × 1.154″) |
|
Resolution |
640 × 360 |
|
Area |
0.2025 ㎡ |
|
Weight |
3.4 kg |
|
Cabinet Material |
Aluminium die casting |
|
Maintenance Method |
Front maintenance for all components |
|
Dimensions |
300 × 168.75 mm |
|
Module Resolution |
320 × 160 |
|
White Balance Brightness |
600 cd/㎡ |
|
Color Temperature |
3000-10000 K adjustable |
|
Viewing Angle |
160°(H)/160°(V) |
|
Contrast Ratio |
15000:1 |
|
Color Uniformity |
≤ ± 0.003Cx，Cy |
|
Brightness Uniformity |
≥ 97％ |
|
Driving Method |
Constant current driving |
|
Scanning Amount |
54 |
|
Frame Frequency |
60 Hz |
|
Refresh Rate |
3840 Hz |
|
Grey Level |
16 bit |
|
Max. Consumption |
≤ 360 W/㎡ （600nits） |
|
Average Consumption |
≤ 120 W/㎡ |
|
Input Voltage |
100~240 VAC ± 10％ |
|
Working Temperature |
-10 ℃ to 40 ℃ (14 ℉ to 104 ℉) |
|
Working Humidity |
10% to 90% RH (without condensation) |
|
Storage Temperature |
-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) |
|
Storage Humidity |
10% to 90% RH (without condensation) |
|
Package Dimensions (W × H × D) |
722 (W) mm × 438 (H) mm × 193 (D) mm (28.425 » × 17.244 » × 7.598 ») |
|
Packing List |
Regulatory Compliance and Safety Information × 1;Several connecting screws, light beads, driver IC, iron sheets |
|
G.W. |
4.56 kg （1 package in 1 box） |
|
Net Weight |
3.4 kg |
|
Modular Bracket |
DS-DL116033W 1*1;DS-DL126033W 1*2;DS-DL226033W 2*2 |
