Hikvision DS-D2046NL-C

Product Model

DS-D2046NL-C

Screen Size

46 inch

Active Display Area

1018.08 (H) mm × 572.67 (V) mm

Backlight

Direct-lit LED backlight

Pixel Pitch

0.53 mm

Physical Seam

3.5 mm

Bezel Width

2.3 mm (top/left), 1.2 mm (bottom/right)

Resolution

1920 × 1080@60 Hz (downward compatible)

Brightness

500 cd/m²

Viewing Angle

Horizontal 178°, vertical 178°

Color Depth

8 bit, 16.7 M

Contrast Ratio

3500:1

Response Time

8 ms (G to G)

Color Gamut

72% NTSC

Surface Treatment

Haze 25%, 2H

Video & Audio Input

HDMI × 1, DVI × 1, VGA × 1, CVBS × 1, USB × 1

Video & Audio Output

DVI × 1, VGA × 1, CVBS × 1

Control Interface

RS232 IN × 1, RS232 OUT × 1

Power Supply

100-240 VAC, 50/60 Hz

Power Consumption

≤ 111 W

Standby Consumption

≤ 0.5 W

Working Temperature

0°C to 40°C (32°F to 104°F)

Working Humidity

20% to 90% RH (non-condensing)

Storage Temperature

-20°C to 65°C (-4°F to 149°F)

Storage Humidity

5% to 90% RH (non-condensing)

Casing Material

SECC

Mounting Hole Pitch

600 (H) mm × 400 (V) mm

Product Dimension (W × H × D)

1021.98 mm × 576.57 mm × 72.2 mm (40.24» × 22.7» × 2.84»)

Package Dimension (W × H × D)

Carton with two displays: 1214 mm × 783 mm × 414 mm (47.8» × 30.83» × 16.3»);Carton with a single display: 1214 mm × 783 mm × 414 mm (47.8» × 30.83» × 16.3»)

Net Weight

18.96 ± 0.5 Kg (41.80 ± 1.1 lb) for single display

Gross Weight

Carton with two displays: 47.12 ± 0.5 Kg (103.88 ± 1.1 lb);Carton with a single display: 25.79 ± 0.5 Kg (56.86 ± 1.1 lb)

Packing List

LCD display × 1, power cable × 1, network cable × 1, screw × 4, installation instruction × 1, remote control × 1, IR receiver × 1, CD-ROM × 1, RS-232 converter × 1
